Influence of Temperature Distribution on Products Quality in 3KA Rare Earth Electrolytic Cell

Abstract:

An investigation was carried out into temperature distribution in 3KA rare earth electrolytic cell and changes of products quality in neodymium electrolysis from a factory in China, The results show that the different temperature distributions have direct effects on the neodymium products quality. In same production cycle, the cell voltage of electrolytic cell is stable and curre rocessing before discharging bascially stays the same; In different cycles, temperature distribution not always alike, mainly reflected in lateral distribution of temperature in electrolytic cell, one form is temperature gradually increased from cathode to anode, and the anode temperature is highest; another is temperature declined then elevated again, anode temperature is slightly higher than the temperature of cathode. The second distribution is benefit for improve the quality of products.

• Periodical: Advanced Materials Research (Volume 800)
• Pages: 496-500
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.800.496
• Online since: September 2013
• Authors: Xiao Lian Zhang, Hong Xia Liu, Xin Zheng, Wei Hua Zhe, Liang Jin, Zhang Jue
• Keywords: Neodymium Electrolysis, Rare Earth Electrolytic Cell, Temperature Distribution

References

[1] Xiaolian Zhang, Shanling Hu, Zuomin Deng, Kejun Wang, Guanghuai Peng, The study of temperature field finite element applied simulate in rare earth electrolytic cell. [J]. Journal of Gannan Normal University, In Chinese. 2007, (03) : 68-70.

[2] Zhongxin Liu, Yongfu Wu, Hongguang Zhang, Electric field simulation of rare earth molten salt electrolytic cell. [J]. Non-ferrous metals(smelting department), In Chinese, 2008(01): 34-37.

[3] Yongfu Wu, Zhongxin Liu, Shuting Li, Electric field numerical simulation of rare earth molten salt electrolytic cell. [J]. Non-ferrous metals(smelting department), In Chinese, 2010(03): 27-30.

[4] Jun Wang, Zuoliang Zhang, Ganfeng Tu, Wenyuan Wu, Electric field simulation of 10KA bottom cathode rare earth molten salt electrolytic cell. [J]. Rare earth, In Chinese, 2010, (04): 36-38.

[5] Haitao Guo, Haijun Jia, Bing Xie, Yonghong Ren, Zuocheng Wang, Energy balance of 3000A electrolytic cell of Nd. [J]. Jiangxi metallurgy, In Chinese. 2007, 27(3): 13-16.

[6] Xiaolian Zhang, Zuomin Deng, Shanling Hu, Kejun Wang, Xuefeng Guo, The application of neural network in rare earth molten salt electrolytic cell. [J]. Journal of rare earths, In Chinese, 2009, 27(2): 306-308.

[7] Zuomin Deng, Xiaolian zhang, Jun Wang, Temperature field numerical simulation in molten salt electrolytic cell. [J]. Non-ferrous metals of Jiangxi, In Chinese , 2004, (01) : 26-27.

[8] Yongfu Wu. simulation and optimal design of rare earth electrolytic cell. [D]. Inner Mongolia University Of Science and Technology, In Chinese, (2007).

[9] Xin Zheng, Weihua Zhu, Guanghuai Peng, Baojun Han and Xiaolian Zhang: The study of temperature distribution of Nd2O3-NdF3-LiF molten salt electrolytic cell. [J]. Journal of Gannan Normal University In Chinese, In Chinese, 2012, 6: 19-21.

[10] Yongfu Wu, Shuyang Li, Jingli Lang, Zhongxin Liu, Electric numerical simulation in molten salt electrolytic cell of preparing Na . [J]. Non-ferrous metals(smelting department), In Chinese, 2011(11): 26-29.

[11] Xianwei Hu, The study of NdF3-LiF-Nd2O3 molten salt structure. [D]. Northeastern university, In Chinese, (2008).

[12] Zhongxin Liu, Feng Cao, Numerical Simulation of Anode Bubble in Nd Electrolytic Cell [J]. Non-ferrous metals(smelting department), In Chinese, 2004(6): 35-37.

[13] GB/T 9967-2010, Nd[S]. In Chinese.
