Study on Cutting Tooth Strength of Spiral Drilling Shearer Based on LS-DYNA

Abstract:

In order to study the structure and shape of the three different cross-sectional shapes of the mechanical properties of the teeth, for the cutter during cutting is immediately effective in the external load and characteristics, the use of LS-DYNA established three different shapes of the flexible structure of the cross-sectional tooth physical model, based on kinetic theory building displays constitutive model based IEF coal wall model. Through the next three shapes cutter cutting process simulation, the cut-off stress at the tooth tip curve and its statistical value, different coals under the stress of each cutting tooth size changes and trends; findings for the study of cross-sectional strength of the shape of its teeth, improving coal cut rate, and improve cutter life work provides an important basis. Auger shearer is the selection, design, personalization adapt and use to provide a new means and methods.

• Periodical: Advanced Materials Research (Volumes 805-806)
• Pages: 1703-1707
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.805-806.1703
• Online since: September 2013
• Authors: Xu Yang*, Zhi Gang Wang, Lei Zhang, Jia Xing Fu
• Keywords: Cutting Tooth, Simulation Analysis, Spiral Drilling Shearer, Strength

References

[1] ShaoRenping. Mechanical system dynamics[M]. Beijing: Machinery Industry Press, (2005).

[2] Li Xiaohuo. Mathematical model of relationship between design parameters and dust explosion rate drum [J]. China Safety Science Journal, 2006. 16(11), 14-17.

[3] Ning Zhongliang, Zhu Huashuang. study on stress distribution of Point-attack pick on [J]. Journal of Xi'an Institute of Technology, 2003(3): 325-327.

[4] Li Xiaohuo. Effect of dust explosion rate from shearer pick arrangement parameters [J]. Journal of Liaoning Technical University, 2007. 25(5), 48-51.

[5] Li Xiaohuo , Jiang Lili. Finite element analysis of shearer gear and gear seat analysis of drilling hard rock screw [J]. Journal of Heilongjiang Institute of Science and Technology, 2009, 19(3): 22 2-224.

[6] Jiao LiLi Xiaohuo etc. The cutter dynamics model and its solving method [J]. Journal of Liaoning Technical University, 2008. 27(2), 85-87.

[7] Li Xiaohuo. Experimental study on point-attack pick cutting [J]. Journal of Liaoning Technical University: Natural Science Edition, 1999, 18(6): 649-652.

[8] Jiao Li. based on dynamics analysis of shearer pick reliability [J]. Journal of Liaoning Technical University, 2006, 25(Suppl. Ⅰ): 249-250.

[9] Wang Chun hua，Ding Renzheng. Cutting simulation test failure process of coal deformation [J]. Journal of China Coal Society, 2006, 31(1): 121-124.

[10] Li Xiaohuo，Shi Xiubao , etc. Parametric design of cutting head of pick arrangement of different test failure process of coal deformation shapes [J]. Journal of Liaoning Technical University, 2009. 19(6), 54-57.

[11] J. Walker, H.S. Yu. Adaptive finite element analysis of cone penetration in clay [J]. Acta•Geotechnica, 2006(4): 43-57.

DOI: 10.1007/s11440-006-0005-9
