Mechanical Reliability of Oxidized Zr-1.1Nb-0.5Cu Alloy Nuclear Cladding Tube in Compression

Abstract:

Ring compression tests on the oxidized Zr-1.1Nb-0.05Cu cladding tubes were performed to examine the mechanical reliability of Zr-Nb-Cu cladding tubes. In compression of the non-oxidized cladding tubes, large load drop associated with the cladding failure appeared at the total displacement of 6.3 mm. After oxidation at 600°C for 24 hrs and 700°C for 3 hrs, small drop of load resulting from small cracks in the thin oxide film was observed at the total displacement of 1.0 mm. After oxidation at 700°C for 24hrs, load was extremely low, but catastrophic fracture occurred at the total displacement of 6.2~6.5 mm. The oxide of Zr-1.1Nb-0.05Cu cladding tubes formed at high temperature apparently causes the premature failure of tubes.

• Periodical: Advanced Materials Research (Volume 813)
• Pages: 91-95
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.813.91
• Online since: September 2013
• Authors: Gu Beom Jeong, Sun Ig Hong
• Keywords: Fuel Cladding, Mechanical Property, Oxidation, Ring Compression, Zirconium Alloy

References

[1] J.A.L. Robertson, J. Nucl. Mater. 100, 108 (1981).

[2] E. Tenckhoff and P.L. Rittenhouse, J. Nucl. Mater. 35, 14 (1970).

[3] E. F Ibrahim, R. Choubey and J.J. Jonas, J. Nucl. Mater. 126, 44 (1984).

[4] R.A. Holt, J. Nucl. Mater. 159, 310 (1988).

[5] W. Liu, Q. Li, B. Zhou, Q. Yan and M. Yao, J. Nucl. Mater. 341, 97 (2005).

[6] J. Y. Park and B. K. Choi, J. Nucl. Mater. 359, 59(2006).

[7] J. Godlewski, Zirconium in the Nuclear Industry, ASTM Spec. Tech. Publ. 1245, 663 (1994).

[8] A.P. Zhilyaev and J.A. Szpunar, J. Nucl. Mater. 264, 327 (1999).

[9] Y. Yan, T.A. Burtseva and M.C. Billone, J. Nucl. Mater. 393, 433 (2009).

[10] M. Steinbrück, M. Böttcher, J. Nucl. Mater. 414, 276 (2011).

[11] Y. Su, G. Fu and Q. Liu, J. Adv. Sci. Lett. 3, 500 (2010).

[12] P. K. Kuiri and M. Ghosh, J. Adv. Sci. Lett. 2, 35 (2009).

[13] Y. Su, G. Fu and Q. Liu, J. Adv. Sci. Lett. 4, 602 (2011).

[14] Z. Yang, J. Hou, Q. Liu and C. Cho, J. Adv. Sci. Lett. 4, 2631 (2011).
