Prediction of Updated Cutting Parameters for a Spindle Subjected to Bearing Wear: A Free Vibration-Based Approach

Abstract:

The effects of spindles vibrational behavior on the stability lobes and the chatter behavior of machine tools are discussed. Multi-segment spinning spindle models, developed based on the Euler-Bernoulli beam bending theory, have revealed that the system exhibits coupled Bending-Bending (B-B) vibration and its natural frequencies are found to decrease with increasing spinning speed. It has also been observed from the experimental data that an average spindle goes through three stages of operation, namely settling, normal operation and failure. As spindle fundamental frequency changes, the stability lobes change, i.e., the originally selected cutting parameters could lead to chatter. It is shown that using the experimental results, it is possible to establish an expression for the variation of spindle's fundamental frequency in terms of machine hours, which can in turn be used to predict chatter-free cutting parameters through calibrated models and the stability lobes.

• Periodical: Advanced Materials Research (Volumes 816-817)
• Pages: 119-123
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.816-817.119
• Online since: September 2013
• Authors: Omar Gaber, Seyed M. Hashemi
• Keywords: Coupled Flexural Modes, Cutting Parameter, Spindle Decay, Spindle Vibrations

References

[1] F.W. Taylor: Trans. ASME, Vol. 28 (1907), pp.31-350.

[2] R.N. Arnold, in: Proceedings of the Institution of Mechanical Engineers, Vol. 154 (1946), pp.429-432.

[3] J.P. Gurney and S.A. Tobias: International Journal of Machine Tool Design Research, Volume 1, Issue 1-2 (September 1961), pp.148-156.

[4] A. Shabana and B. Thomas: Mechanical Machine Theory, Vol. 22, Issue 4 (1987), pp.359-369.

[5] J. Tlusty and F. Ismail: CIRP Annals- Manufacturing Technology, Vol. 30, Issue 1 (1981), pp.299-304.

[6] K. Yoshitaka, K. Osame and S. Hisayoshi: Journal of Engineering for Industry, Vol. 103, Issue 4 (November 1981), pp.324-329.

[7] J. Tlusty and F. Ismail: Journal of Vibration, Acoustics, Stress, and Reliability in Design, Vol. 105, Issue 1 (January 1983), pp.24-32.

[8] O.B. Adetoro, P.H. Wen, W.M. Sim and R. Vepa R., in: Proceedings of World Congress on Engineering (1-3 July 2009), pp.520-525, London, U. K.

[9] O. Gaber and S.M. Hashemi, Advanced Materials Research Vol. 651 (2013), pp.710-716.

[10] JR. Banerjee: Computers & Structures, Vol. 63, Number 1 (April 2007), p.101–103.
