Numerical Investigation on the Process of Stretch-Forming Based on Discretely Loading for Spherical Sheet Metal Parts

Abstract:

Stretch-forming based on discretely loading is a new process for manufacturing three-dimensional sheet metal part, the stretching load is applied at discrete points on the two ends of sheet metal, by controlling the loading trajectory at each discrete point, an optimal stretch-forming process can be realized, and the formed surface with the strains and stresses more uniformly distributed are obtained so that the forming defect can be avoided. The numerically investigated results on the stretch-forming process of spherical sheet metal part show that, comparing with the traditional stretch-forming, the equivalent strain in the new process is reduced by approximately 30% and equivalent stress reduced by 10%, the range of the strain and stress distributions are reduced by approximately 30%.

• Periodical: Advanced Materials Research (Volumes 816-817)
• Pages: 682-685
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.816-817.682
• Online since: September 2013
• Authors: Zhong Yi Cai, Mi Wang, Zhen Yang, Kun Peng
• Keywords: Curved Surface, Discretization, Loading Trajectory, Sheet Metal, Stretch-Forming

References

[1] J. M. Papazian. Mechanical Engineering, Vol. 124 (2002), p.52.

[2] E. L Anagnostou. Optimized tooling design algorithm for sheet metal forming over reconfigurable compliant tooling. New York: State University of New York (2002).

DOI: 10.1063/1.1766615

[3] Z. Y. Cai, M.Z. Li. International Journal of Pressure Vessels and Piping , Vol. 79 (2002), p.289.

[4] Z. H. Zhou, Z. Y. Cai, M.Z. Li. Journal of Jilin University (Engineering and Technology Edition) , Vol. 35 (2005), p.287. (in Chinese). Dj.M. Maric, P.F. Meier and S.K. Estreicher: Mater. Sci. Forum Vol. 83-87 (1992), p.119.

[25] M. Z. Li, Z. Y. Cai, C. G. Liu. Robotics and Computer-Integrated Manufacturing, Vol. 23 (2007), p. 107M.A. Green: High Efficiency Silicon Solar Cells (Trans Tech Publications, Switzerland 1987).

[6] Z.Y. Cai, S.H. Wang, X.D. Xu et al. Journal of Materials Processing Technology, Vol. 209 (2009), p.396.

[7] S. H. Wang, Z. Y. Cai, M. Z. Li. International Journal of Advanced Manufacturing Technology, Vol. 49 (2010), p.475.

[3] Y. Mishing, in: Diffusion Processes in Advanced Technological Materials, edtied by D. Gupta Noyes Publications/William Andrew Publising, Norwich, NY (2004), in press.

[4] G. Henkelman, G. Johannesson and H. Jónsson, in: Theoretical Methods in Condencsed Phase Chemistry, edited by S.D. Schwartz, volume 5 of Progress in Theoretical Chemistry and Physics, chapter, 10, Kluwer Academic Publishers (2000).

[5] R.J. Ong, J.T. Dawley and P.G. Clem: submitted to Journal of Materials Research (2003).

[6] P.G. Clem, M. Rodriguez, J.A. Voigt and C.S. Ashley, U.S. Patent 6, 231, 666. (2001).

[7] Information on http: /www. weld. labs. gov. cn Zhong-yi Cai, Shao-Hui Wang, Xu-Dong Xu, Ming-Zhe Li. Numerical simulation of multi-point stretch forming process of sheet metal，Journal of Materials Processing Technology, 209(1): 396-407, 2009 Shaohui Wang, Zhongyi Cai*, Ming-zhe Li. Numerical investigation of the influence of punch element in multi-point stretch forming process, The International Journal of Advanced Manufacturing Technology, 49（5-8）：475-483, (2010).

DOI: 10.1007/s00170-009-2420-1
