Research on Neutral Grounding Reactance Allocation with MCR

Abstract:

For the arc current generated during the reclosing of the high-voltage transmission system, small reactance configuration compensation and control strategy. By the magnetically controlled reactor is researched. First analyzing the principle that high-pressure single-circuit and double-circuit on the same pole line suppresses arc current, then establishing the magnetron controlled reactor equivalent model in PSCAD, on this basis, establishing simulation using magnetron reactors to suppress secondary arc current circuit under the conditions of high voltage transmission lines , designing and implementing of a magnetic valve controllable reactor inhibition of arc current physics experiments under of a low-voltage experimental conditions analoging high-voltage actual line condition. At last, the comparison of PSCAD simulation waveform and physics experiments of Power Quality the analyzer topas2000 and oscilloscope output verify the magnetic valve controllable reactor to suppress the arc current theory feasibility and effectiveness.

• Periodical: Advanced Materials Research (Volumes 816-817)
• Pages: 997-1001
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.816-817.997
• Online since: September 2013
• Authors: Ren Wei Liu, Zhong Dong Yin, Song Wei Cao, Heng Rui Ma
• Keywords: Arc Current, High Voltage Transmission Line, Magnetically Controlled Reactor, Small Reactance in Neutral Point, Topas2000

References

[1] Liu Zhen-ya． High Voltage Power Grid [M]. BeiJing: China Economic Publishing House, (2005).

[2] HAN Bin, LIN Ji-ming, BAN Lian-geng, ZHENG Bin, ZHANG Yuan-yuan, WANG Xiao-tong. Study on Single-Phase Reclosing Issues for 1000 kV UHVAC Transmission Pilot Project [J]. Power System Technollogy, 2006, 16(33): 20-23.

[3] Edward W. Kimbark. SELECTIVE-POLE SWITCHING OF LONG DOUBLE-CIRCUIT EHV LINE. IEEE Transactions on Power Apparatus and Systems, 1976, PAS-95(1), 219-230.

DOI: 10.1109/t-pas.1976.32095

[4] Liu Zhen-ya. UHV AC transmission technology research album(2005). BeiJing: China Economic Publishing House, (2006).

[5] Zhou Yuan-qing. Application of Magnetically Controlled Reactors in UHV AC Transmission Lines: [D]. HuNan: Hunan University, (2008).

[6] Zhou Li-xia. Mathematical Analysis and Simulation Research of Magnetic Valve Controllable Reactor: [D]. BeiJing: North China Electric Power University, (2006).

[7] Wang Hao, Li Yong-li, Li Bing. Secondary arc extinction methods for 750 kV and UHV transmission lines. Electric Power, 2005, 38(12), 29-32.
