Crankshaft Composite Lathe’s Tool Tip Trajectory Error Analysis and Simulation

Abstract:

The crankshaft composite follow crankshaft turning lathes use the following tool system to complete the turning of crankshaft, when crankshaft machining is working, the turret mechanisms processing error and assembly errors will affect the crankshafts processing quality, So it is difficult to control the actual machining accuracy, or it may cause the waste of material. Therefore, in this paper, by analyzing the impact of the rod length errors on the trajectory of the tool tip, the tool tip trajectorys equations can be built. Using MATLAB tools, we can build the tip point trajectory modeling and solve the deviation between the actual tip point and the ideal trajectory, and finally can get the result of rod lengths error on the accuracy of the actual processing, which will provide basis for the design and analysis in future.
