Research on Torsional Vibration Analysis of Herringbone Gear Pairs without Groove

Abstract:

A torsional dynamic model of a pair of herringbone gear was presented by using a lumped-mass method, in which the meshing integrated error and time-varying meshing stiffness of the herringbone gear pair were taken into account at the same time. A Rugge-Kutta method was used to solve the dynamic differential equations of the system and the dynamic characteristics of the herringbone gear pair under the action of the external torque and internal excitations were obtained. The study provides a theoretical basis with the future other complex multistage herringbone gear drive system dynamics.

• Periodical: Advanced Materials Research (Volume 823)
• Pages: 276-279
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.823.276
• Online since: October 2013
• Authors: Fei Ren*, Da Tong Qin, Xiao Ling Wu
• Keywords: Comprehensive Meshing Error, Herringbone Gear Pair, Time-Varying Meshing Stiffness, Torsional Vibration Analysis

References

[1] Kahraman A, Blankenship G W. Journal of Applied Mechanics, Vol. 64 (1997) NO. 1, pp.217-226.

[2] Parker R, Vijayakar S M, Imajo T. Journal of Sound and Vibration, Vol. 237(2000) NO. 3, pp.435-455.

[3] A.S. Kumar et al, ASME Journal of Mechanisms, Transmissions and Automation in Design, Vol. 107 (1985) No. 1.

[4] M. Benton and A. Seireg, ASME Journal of Mechanical Design , Vol. 102 (1982). NO. 2.

[5] Cai Y. ASME Journal of Mechanical Design, Vol. 117(1995): No. 9, pp.460-468.
