Design of Temperature Control System Based on DSP and Fuzzy Neural Network

Abstract:

Using fuzzy neural network to tune PID parameters, and DSP as processor, it was designed that a set of electric boiler temperature control system based on PID parameters self-tuning, including the design of each hardware module and each software subroutine of the system. Experimental results show that compared with the traditional PID temperature control system, this temperature control system has the advantages such as good control effect, easy parameter adjustment, strong anti-jamming capability, better adaptability and robustness, has the feasibility and practical value.

• Periodical: Advanced Materials Research (Volume 823)
• Pages: 384-387
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.823.384
• Online since: October 2013
• Authors: Ya Juan Chen, Yue Hong Zhang, Gen Wang Ying
• Keywords: Digital Signal Processor (DSP), Fuzzy Neural Network (FNN), PID Controller, Temperature Control System

References

[1] WANG H B, YANG X L, WANG H R. An Improved Learning Algorithm for RBF Neural Networks[J]. Systems Engineering and Electronics. 24 (6): 103-105, (2002).

[2] Xinmin Shi. Fuzzy Control and MATLAB Simulation. TSINGHUA UNIVERSITY PRESS, Beijing, (2008).

[3] D.L. Liu, Y.Y. Wang, and J.Y. Zhang. Simulation Study of the Neural Network Fuzzy PID Control Method in the Temperature Control of the Greenhouse. Journal of Agricultural Mechanization Research, no. 10, pp.50-52, (2006).

[4] Xin Fang, Hongshe Dang. Design and Implementation of High-speed Fuzzy PID Temperature Controller. Control and Instruments In Chemical Industry, Vol 36, pp.75-77, June 2009 (In Chinese).

[5] Khan AA, RapalN. Fuzzy-PID controller: design, tuning and comparison with conventional PID controller[C]. Proc of the 2006 IEEE International Conference on Engineering of Intelligent System. China: IEEE ComputerPress, 2006: 1-6.

DOI: 10.1109/iceis.2006.1703213
