Validation of the Method for Generation of Rheological Model to Characterize Non-Conventional Injection Molding by Means of Spiral Mold

Abstract:

This paper presents the results derived from the research, whose first results were presented at AMPT 2005. At this conference, a new method for generation of rheological model to characterize non-conventional injection moulding by means of spiral mould was presented. The continuity of this research line has consisted of the development of several tests for validation of the rheological model obtained with the new method. Viscosity of a PEHD with different percentages of recycled has been tested, by means of several kinds of rheometers, like capillary rheometer and rotational rheometer, and the results has been compared to those obtained with the spiral mould. Conclusions of this research show the suitable parameters range, at which the results are comparable for the new method. On the other hand, another work line for the validation of the rheological models has begun, by applying the models to CAE injection moulding software, and checking the results by experimental trials with a industrial mould. This mould has been adapted to register pressure results during injection cycle. These trials take into account the influence of most of the injection process parameters, as well as different percentages of recycled.

• Periodical: Advanced Materials Research (Volumes 83-86)
• Pages: 250-260
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.83-86.250
• Online since: December 2009
• Authors: Carlos Javierre, L. Ponz, Isabel Clavería, A. Fernández
• Keywords: Injection, Pressure, Recycled, Rheology

References

[1] Menges, Mohren, How to make injection moulds, (2nd edn. Hanser 1993).

[2] Rosenbaum E E, Hatzikiriatos S G., Effect of viscous heating in capillary rheometry, Proc. Antec'94 Conference, (1994).

[3] Brandrup J, Bittner M, Michaeli W., Recycling and recovery of plastics, (HanserHanser/Gardner 1996).

[4] Deanin RD, Amran A, Saraogi R, Matani N., Recycle of Polystirene: Pol Preprints Vol. 2 (1983), pp.430-431.

[5] Hoffman DA, Effect of recycled phenolics on processing", Proc. Antec, 94 Conference (1994).

[6] Vosshenrich B, Higher proportions of recycled material can be used: Kunststoffe Synthetics Vol. 5, (1993) pp.15-18.

[7] Albertsson A, Huang SJ, Degradable Polymers, Proc. Recycling & Plastics Waste management, (1995).

[8] Scheirs, Polymer Recycling: Science, Technology & Applications, (John Wiley & Sons 1998).

[9] Dontula N, Campbell G A, Wenskus J J, Approach towards moulding parts with constant properties on addition of regrind, Proc. Antec'94 Conference (1994).

[10] C. Javierre, I. Claveria, L. Ponz, A. Fernandez: Waste Mngment. Vol. 27 (2007), pp.656-663.

[11] Abbas KB: Pol. Eng. Sci. Vol. 10 (1980). pp.703-707.

[12] Gucerin, S.I., Finite Difference Solution of Field Problems in Computer Modeling for Polymer Processing (Ed. Tucker C.L., Hanser 1989).

[13] Nichetti D, Manas-Zloczower I: J Rheology Vol. 4 (1998) pp.951-969.

[14] Pillo A, Dealy J M, Patterson W I: Int. Pol. Proc. Vol. 1 (1997) pp.4-10.

[15] C. Javierre, I. Claveria, L. Ponz: J. Mat Proc Tech. Vol. 162-163 (2005) pp.477-483.

[16] Amano O, Ainoya K, Pressure dependent viscosity of polymer melts, Proc. Antec'00 Conference Proceedings (2000).

[17] Barnes, H.A., Hutton, J.F., Walters, K., An introduction to rheology, (Elsevier Science Publishers B.V. 1989).

[18] Lee, C.C., and Castro, J.M., Model Simplification in Fundamentals of computer modelling for Polymer Processing (Ed. C.L. Tucker III Hanser Publishers 1989).

[19] Scriven T, Sykes S, Analysis of pre-consumer regrind in an injection moulded thermoplastic part, Proc. Antec'95 Conference (1995).

[20] C. Javierre, D. Mercado, A. Fernandez, M. Muniesa, Characterization of defects of large thermoplastic parts during injection and packing stages by means of monitorized nozzle to improve parts quality, Proc. 6th International Conference on Industrial Tools and Material Processing Technologies, Bled (2007).
