Introduction of a Device for Automatic Collection of Potential Data and its Application in Pipeline

Abstract:

The pipeline cathodic protection monitoring was used in potential test of cathodic protection in pipeline. The test period was last 1 or 2 months or longer. the measurement accuracy and reliability of testing data are affected by testing environment and the accuracy of the instrument in some ways, so in order to meet the requirement of cathodic protection potential monitoring, it is necessary to design a cathodic protection potential acquisition system to realize the automatic monitoring of cathodic protection potential, the system was an automatic acquisition pipeline potential device used in buried steel pipeline environment. The internal circuits of the device used single chip design of low power consumption and are high precision DC voltage and AC voltage effective value measurement device all based on AVR MCU, combining hardware with software, the results show that the system realizes the automatic acquisition of buried pipeline potential and completes the indicators in China.

• Periodical: Advanced Materials Research (Volumes 834-836)
• Pages: 1150-1155
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.834-836.1150
• Online since: October 2013
• Authors: Rui Ying Cao*, Zhi Yuan Xue, Hong Yuan Chen, Kai Shuang, You Wen Jiang, Ming Bo Wang
• Keywords: Automatic Potential Acquisition, Hardware and Software, Low Power Chips, Voltage Measurement

References

[1] Lawson, W. D. Power Apparatus and Systems, (1978).

[2] Chao Ma, et al. Principle and practice application of AVR embedded system, Beihang University press, 2011，the second edition. (In Chinese).

[3] Benxin Gan, Hongyan Sun. science. 2008. (In Chinese).

[4] Yanling Shi, Laizhi Zong Zhiqiang Yan. Journal of Electrician Technique. 2003, (5): 34-35, 38. (In Chinese).

[5] Guangyu Xiong, Foreign electronic components, 1995. (In Chinese).

[6] Qingqing Ge, Tianzgang Shao, Electrical measurement and instrumentation. 2012，(In Chinese).

[7] Yang Yong, Xiaoou Chen. Design circuit Altium Designer09 standard course. Science Press，2011. (In Chinese).
