Forces Analysis of Piston Couple in Swash-Plate Axial Piston Motor

Abstract:

Hydraulic motor is an important hydraulic component in hydraulic control system, so the analysis of its performance is very important. The piston couple is one of the most important frictional pairs in axial piston motor, this paper studies the forces on the piston couple of swash-plate axial piston motor. It deduces the mathematical model of forces analysis in arbitrary phase of the cylinder, and the forces of a type of axial piston motor are analyzed. And it gives suggestions for structure optimal design of piston couple.

• Periodical: Advanced Materials Research (Volumes 834-836)
• Pages: 1319-1322
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.834-836.1319
• Online since: October 2013
• Authors: Jin Yan Shi
• Keywords: Forces Analysis, Piston Couple, Value of [p

References

[1] Li Z Y, Hydraulic components and system [M], Beijing: Publishing House of Machinery Industry, (2005).

[2] He C X, Hydraulic components [M], Beijing: Publishing House of Machinery Industry, (1981).

[3] Zhu W　B，Zhang Y W. lubrication Analysis of piston seal friction couple in piston pump [J]. Journal of Sichuan Institute of Technology, (2004).

[4] Guo W D, Wang Z L, Analysis and Study on the oil pressure of inner cavity piston of piston pump [J]. Machine Tools and Hydraulic, (1996).

[5] Zhang H J, Huang Y, Hydraulic Transmission [M]. Beijing: Publishing House of Machinery Industry, 1999, 10).
