Engineering Calculation and Application of Perforation Impact Dynamic Loads in Oil and Gas well

Abstract:

The perforation impact dynamic loads can destroy or disable the tubing strings. The perforated completion process was simplified to explosion of ordinary explosive charge in perforation liquid. The dimensionless expression of perforation impact dynamic loads was derived based on main influence factors and then its engineering calculation formula was set up. A well perforation operation in western Sichuan as an example, the oil tubing strings security was analyzed by the perforation impact dynamic loads from the engineering computation formula. The results show that the tubing strings only occur elastic spiral bucking and do not occur plastic deformation which are in line with perforation operation results on site.

• Periodical: Advanced Materials Research (Volumes 834-836)
• Pages: 1308-1312
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.834-836.1308
• Online since: October 2013
• Authors: Cheng Bing Li, Yong Liang, Zhong Kai Lou
• Keywords: Engineering Calculation, Impact Dynamic Load, Perforation, Tubing String

References

[1] Hongdong Yin, Jianjun Zhang. Mechanics analysis of Preforating Combined Well Testing String and Protection Technology of Downhole Instrument[J]. Oil Drilling & Production Technology, Vol. 25 (2003), pp.61-63. (In Chinese).

[2] Li Zhang, Quanbang Zhu. Fault analysis of Familiar Pressure Gauge and Clock in Testing the Construction with Perforation[J]. Well Testing, Vol. 12 (2003), pp.61-62. (In Chinese).

[3] Yihua Dou, Haijun Xu, Xuehai Jiang, etc: Damage cause analysis of the packer central tube China Petroleum Machinery, Vol. 3 (2007), pp.113-115. (In Chinese).

[4] Feng Chen,  Huabin Chen,  Kai Tang. Influence of perforation impact load on the operating string and the countermeasures [J]. Natural Gas Industry, Vol. 30 (2010), pp.61-65, 141.

[5] Schatz, J. F., Haney, B. L. And Ager, S. A. High-Speed Downhole Memory Recorder and Software Used to Design and Confirm Perforamtiong/Propellant Behavior and Formation Fracturing. Paper SPE 56434 presented at SPE Annual Technical Conference and Exhibition, Houston (1999).

DOI: 10.2118/56434-ms

[6] Schatz, J. F., Folse, K. C., Fripp, M., and Dupont, R. High-Speed and Accelerometer Measurements Characterize Dynamic Behavior During perforation Events in Deepwater Gulf of Mexico. Paper SPE 90042 presented at SPE Annual Technical Conference and Exhibition, Houston (2004).

DOI: 10.2118/90042-ms

[7] Canal, A., Miletto, P., Schoener-Scott, M., Medeiros, J., and Barlow, D. Predicting Pressure Behavior and Dynamic Shock Load on Completion Hardware During perforation. Paper OTC-21059 presented at Offshore Technology Conference, Houston (2010).

DOI: 10.4043/21059-ms

[8] Burman, J., Schoener-Scott, M., Le, C., and Suire, 220 D. Predicting Wellbore ynamic-Shock Load Prior to perforation. Paper SPE 144059 presented at SPE Annual Technical Conference and Exhibition, Houston (2011).

DOI: 10.2118/144059-ms

[9] Chengbing Li, Jin Xiong and Mingyong Ma. Theoretical and Experimental Research on Perforation Remnant Energy. Advanced Materials Research, Vol. 339, 2011, pp.379-385.

DOI: 10.4028/www.scientific.net/amr.339.379

[10] R. H. Cole. Underwater Explosions. Princeton Univ. Press, Princeton, USA, (1948).

[11] Qingming Tan. Dimension analysis[M]. University of Science and Technology of China Press, Hefei, China, 2005. (In Chinese).

[12] Chengbing Li and Mingyong Ma. Numerical Computation of Wellbore Dynamic Pressure during perforation. In Computational and Information Sciences of International Conference. (IEEE). Chongqing (2012). (In Chinese).

[13] Shaohua Jin, Quancai Song in: Explosive Theory. Northwestern Polytechnical University Press, Xi'an, China, 2010. (In Chinese).

[14] Zifeng Li. Oil and gas Wells Rod String Mechanics[M]. Petroleum Industry press, Beijing, 2008. (In Chinese).
