Dynamic Load of Agricultural Machinery Drive Axle Housing Based on Field Measured Road Roughness

Abstract:

The dynamic load on drive axle housing has great significance for analyzing the strength of drive axle housing and studying the reliability life of drive axle housing, and road roughness has an important impact on dynamic load of drive axle housing. In this paper, the drive axle housing of agricultural machinery is select as the research object. Firstly, the dynamic model of the drive axle housing is established, and the vibration equation is calculated by Laplace transform and Laplace inverse transform, and then the vibration load time history is given based on the discrete data of road roughness obtained by field experiment. At last, the rainflow counting method is used to generate the load spectrum. The study has a certain reference and application value for the optimization design of drive axle housing of agricultural machinery.

• Periodical: Advanced Materials Research (Volumes 834-836)
• Pages: 1295-1298
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.834-836.1295
• Online since: October 2013
• Authors: Li Xiang Zhang*, Shou Rong Liu, En Rong Mao, Bin Xie, Xin Jia Meng
• Keywords: Agricultural Machinery, Dynamic Load, Load Spectrum, Rainflow Counting, Road Roughness

References

[1] P.M. Lü, J.M. You and L.M. He: Journal of Traffic and Transportation Engineering. Vol. 7(6) (2007), P. 54 (In Chinese).

[2] Y.Q. Lou, W.L. Zhao and Q.H. Meng: Mechanical & Electrical Engineering Magazine. Vol. 26(3) (2009), P. 61 (In Chinese).

[3] X.N. Fan, G.N. Xu and A.H. Wang: Journal of Mechanical Engineering. Vol. 48(18) (2012), P. 192 (In Chinese).

[4] Y. Ling, C. Shantz, S. Mahadevan and S. Sankararaman: International Journal of Fatigue. Vol. 33(7) (2011).

[5] X. T Nie, L.X. Shi, H. Gu and S.H. Zhu: Journal of Nanjing Agricultural University. Vol. 34(5) (2011): P. 139 (In Chinese).
