The Mechanical Performance Evaluation of a Mechanism with Curved Edge Driving Component

Abstract:

Mechanicalmethods were employed to study the motion and force transmission performance ofa kind of connecting rod slider mechanism with a curved edge driving component.The deduction methods and the computation formulae of the slider displacement,velocity, acceleration and the executive force gain coefficient were given.Considering two cases of the driving components with straight line edge andexponential function edge, the numerical examples was computed respectively,the results show that the former one is suitable for the force transmission andcan be used in the grip design and the other one is suitable for the motiontransmission which can be used in the fast moving mechanism

• Periodical: Advanced Materials Research (Volumes 834-836)
• Pages: 1290-1294
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.834-836.1290
• Online since: October 2013
• Authors: Xin Qin Liu
• Keywords: Connecting Rod Slider Mechanism, Curved Edge Driving Component, Executive Force Gain Coefficient, Mechanical Analysis, Motion Transmission

References

[1] Hai Jiao Zhang, A Ling Zhang, Jin Ming Li: Design & Manufacture of Diesel Engine Vol. 17(4) ( 2011), p.23 (In Chinese).

[2] Meng Zhaoming, Tang Ren-gang, Zhao Haixia, et al.: Journal of Machine Design Vol. 24(9) (2007), p.42 (In Chinese).

[3] LU Keming, WANG Yong: Journal of naval university of engineering Vol. 23(1) (2011), p.84 (In Chinese).

[4] GUO Xinglin, ZHAO Zikun: Journal of Mechanical Strength Vol. 32(6)(2010), p.905 (In Chinese).

[5] WANG Guoqing, LIU Hongzhao, HE Changan: Journal of Mechanical Strength Vol. 28(6) (2006), p.849 (In Chinese).
