Automatic Process Intermediate Model Generation in Process Planning

Abstract:

In process planning of machined part, three-dimensional process intermediate models are necessary for process design, documentation, and downstream applications including clamping design, NC programing, and process analysis. An automatic process intermediate model generation method is proposed in this paper for machined part represented in B-Rep solid model. Machining features are recognized and classified according to process type. Process plan is expressed in terms of machining features and feature surface modification operations in solid model. Local modification operations are applied to part model to move, replace or remove feature surface resembling machining process. Process intermediate models are generated automatically in a batch manner by applying geometry and topology modification operations directly on B-Rep model for each machining operation. The proposed algorithm is implemented in a CAPP tool developed in solid modeler ACIS.

• Periodical: Advanced Materials Research (Volumes 834-836)
• Pages: 1436-1443
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.834-836.1436
• Online since: October 2013
• Authors: Xu Zhang*, Chao Liang, Wei Yu Li
• Keywords: CAPP, Feature Recognition, Machining Feature, Process Intermediate Model

References

[1] Verma, Arvind Kumar andRajotia, Sunil, 2010, A review of machining feature recognition methodologies, International Journal of Computer Integrated Manufacturing, 23: 4, 353- 368.

DOI: 10.1080/09511921003642121

[2] NandakumarSridharan, Jami J. Shah, 2004, Recognition of multi axis milling features: part I – topological and geometric characteristics, Journal of Computing and Information Science in Engineering, September 2004, v4, 242-250.

DOI: 10.1115/1.1778718

[3] NandakumarSridharan, Jami J. Shah, 2005 Recognition of multi-axis milling features: part II – algorithms & implementation, Journal of Computing and Information Science in Engineering, March 2005, v5, 25-34.

DOI: 10.1115/1.1846054

[4] M. Gulesin. Intermediate part modeling in a process planning and fixturing system[J]. Robotics&Computer-Integrated Manufacturing，1996, 12(04): 321-328.

DOI: 10.1016/s0736-5845(96)00018-x

[5] Ramesh M, Belludi N, Yip-Hoi D, Dutta D, Wascher P. Application of feature technology to modeling and dimensioning the intermediate geometry of automotive powertrain components. Proceedings seventh ACM symposium on solid modeling and applications，Saarbrucken，Germany，2002，313-320.

DOI: 10.1145/566282.566327

[6] Derek Yip-Hoi, Jianming Li, Liang Zhou, Wencai Wang, Madhumati Ramesh, Samba Subramanian, Steve Swisher. A framework for integrated computer-aided design, process planning and manufacturing systems engineering for powertrain machining. ASME 2004 Design Engineering Technical Conferences and Computers and Information in Engineering Conference，Salt Lake City，Utah，USA，2004，4: 79-89.

DOI: 10.1115/detc2004-57656

[7] Park SC. Associating a Design Model and its Machining Process Plan. Computer-Aided Design & Applications，2005，2(05): 665-673.

DOI: 10.1080/16864360.2005.10738331

[8] http: /www. designrepository. org.
