Modeling of Strain and Stress States for Straight Rods with Particular Cross Sections Subjected to Torsion

Abstract:

In the case of shaft-hub joints with cylindrical pins found in both macro and micro-devices, a longitudinal gutter with an almost half-circular cross section is practiced along the length of the shaft segment. The center of the circular arc is placed on the circular edge of the cross section. The present paper aims to model strain and stress states within such a shaft, when the material elastic properties are known along with shaft segment length and applied torque. Using the MathCad environment, 3D and constant stress level plots were obtained for the distribution of tangential stresses over the cross section. After application of torque, the transverse cross sections shift and become anti-symmetric as illustrated by the obtained 3D and constant strain plots.

• Periodical: Advanced Materials Research (Volume 837)
• Pages: 699-704
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.837.699
• Online since: November 2013
• Authors: Marilena Glovnea, Cornel Suciu
• Keywords: Modeling, Particular Cross Sections, Straight Rods, Strain States, Stress States, Torsion

References

[1] Belyaev, N. M., Strength of Materials, MIR, Moscow, (1979).

[2] Diaconescu, E., Glovnea, M., Elemente de teoria elasticităţii cu aplicaţii la solicitări simple, Editura Universităţii din Suceava, ISBN 978-973-666-284-5, Suceava, (2007).

[3] Goia, I., Mechanics of Materials, First volume, Derc Publishing House, (2009).

[4] Timoshenko, S., Strength of Materials, Part II, Advanced, Van Nostrand Reinhold, New York, Third edition, (1970).
