Numerical Analysis of Reinforced Concrete Bridge Panel Fatigue Based on Midas

Abstract:

Under the process of numerical analysis of fatigue failure of panel of highway reinforced concrete bridge , numerical analysis method is put forward , which can simulate process of fatigue damage degradation of the bridge deck under the vehicle load . In the first , complex vehicle load is equated simplistically on the basis of the national related tests and research with formulating load spectrum reasonably; Then modeling analysis by Midas software , it carries out that fatigue constitutive relation between steel and concrete material is correct among the flexural member under cyclic load ; Finally , an actual reinforced concrete bridge panel is predicted fatigue life and made fatigue numerical analysis . Results show that the fatigue life of the panel meets the requirements; Building material fatigue constructive relations can simulated rule of mechanics performance attenuation of steel and concrete effectively in the course of cyclic loading.

• Periodical: Advanced Materials Research (Volumes 838-841)
• Pages: 1048-1053
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.838-841.1048
• Online since: November 2013
• Authors: Da Wei Zheng*, Yu Hui Zhang, Guang Hua Li, Xu Zhang, Lin Liu
• Keywords: Cyclic Loading, Fatigue Constitutive Relation, Numerical Simulation, Reinforced Concrete Bridge Panel

References

[1] Jun-ying Ge. Bridge Engineer [M]. Beijing: China Railway Publishing House(in Chinese), (2002).

[2] Hua Pan. Experimental Study on Fatigue performance of Concrete Member in Bending [D]. Nanjing: Southeast University(in Chinese), (2006).

[3] Yu-pu Song. Fatigue Behavior and Design Principle of Concrete Structures [M]. Beijing: China Machine Press(in Chinese), (2006).

[4] Jin-song Zhu, Yu-pu Song, Ru-cheng Xiao. Fatigue Behavior and Post-damaged Equivalent Constitutive Law of Plain Concrete [J]. Journal of Building Materials(in Chinese), 2005, 8(6): 609-614.

[5] Lin-fei Pang. Fatigue Cumulative Damage Detection and Fatigue Life Prediction on Reinforced Concrete Slabs [D]. Nanjing: Southeast University(in Chinese), (2004).

[6] Kim C W, Kawatani M, Kwonb Y R. Impact Coefficient of Reinforced Concrete Slab on a Steel Girder Bridge [J]. Engineering Structures, 2007, 29(4): 576-590.

DOI: 10.1016/j.engstruct.2006.05.021

[7] Le-wei Tong, Zu-yan Shen, Zhong-yan Chen. Fatigue Load Spectrum for Urban Road Bridges [J]. China Civil Engineering Journal(in Chinese), 1997, 30(5): 20-27.
