The Influence of Pile-Pier Reinforcement Ratio on the Development of Plastic Zone of Bridge Structure

Abstract:

In this paper, using elastic-plastic fiber unit model for a continuous beam bridge structure and foundation to analyses the nonlinear seismic response of pier and pile foundation considering pile-soil interaction and the different types of seismic wave on the pile foundation and the pier dynamic response, focusing on the development of plastic zone and dynamic response of structure under different pile-pier reinforcement ration conditions. The results show that, with the pile pier reinforcement ratio increases, the response plasticity of pile and pier show a different trend; so pile-pier reinforcement ration is an important factor of dynamic characteristics for the bridge pier supported by group piles system; the pier reinforcement ratio not only impact on development of the plastic zone of the pier, but also impact on the pile. In addition, different types of seismic waves on the structure are different, the long-period seismic waves maximum, followed by inland direct seismic waves, plate boundary seismic wave minimum.

• Periodical: Advanced Materials Research (Volumes 838-841)
• Pages: 1058-1062
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.838-841.1058
• Online since: November 2013
• Authors: Bo Song, Kai Wen Li*, Min Zhong
• Keywords: Bridge Structure, Ground Motion, Pile-Soil Interaction, Plastic Zone, Reinforcement Ratio

References

[1] Waston S, Zahn S A and Park R. Confining Reinforcement for Concrete Columns. J. Structural Eng., AECE, 1994, Vol. 120(6): 1798.

DOI: 10.1061/(asce)0733-9445(1994)120:6(1798)

[2] Chang G A, Mander J B. Seismic energy based fatigue damage analysis of bridge columns: Part I evaluation of seismic capacity. /NCEER Technical Report, New York , (1994).

[3] Liu Q H, Fan L Z. Theoretical research on the ductility of reinforced concrete bridge piers. Journal of Tongji University, 1998, 26(3): 245.

[4] Wang L X, Yang Z, Wang H C, Takayuki Obara. Experimental study on seismic behavior of RC bridge pier using new type of combined stirrup (S-Clip). Journal of Vibration and Shock, 2011, 30(3): 211.

[5] Li F Y, Shen Y, Li G P, Guan Y J. Analysis of parameters to shear capacity of long-san continuous rigid girder bridge. Journal of Tongji University(Natural Science), 2007, 39(9): 1169.

[6] Fu Y H. Discussion on minimum amount of confining stirrups and shear strength of pier at plastic hinge area in bridge anti-seismic design code. Bei Fang Jiao Tong , 2012, (4): 111.

[7] Lu Y, Xu L H, Li Z X, Ding Y. Damage and failure analysis of reinforced concrete frame structure using fiber element model. Journal of Tianjin university, 2011, 44(10): 925.

[8] Chongqing Communications Research & Design Institute. JTG/T B02-01-2008 Guidelines for Seismic Design of Highway Bridges. Beijing, china Communications Press, (2008).

[9] Ministry of Housing and Urban-Rural Development, People's Republic of China. GB50010—2010. Code for Design of Concrete Structures. Beijing: China Architecture & Building Press, (2010).

[10] Kent D C, Park R. Flexural members with confined concrete. Journal of the Structural Division, 1971, 97(7): (1960).

[11] Zhao G F. Advanced Reinforced Concrete Structural Analysis. Beijing: China Machine Press, (2005).

[12] Ministry of Housing and Urban-Rural Development, People's Republic of China. GB50011—2010 Code for Seismic Design of Building. Beijing: China Architecture & Building Press, (2010).
