Nonlinear Finite Element Analysis of Masonry Wall Strengthened with Steel Strips

Abstract:

The finite element analysis method was adopted to simulate the masonry wall strengthened with steel strips and was verified by comparing with test results. The influence rules of two factors including the cross sectional area of steel strips and vertical compression were investigated. The results show that, as for unreinforced masonry wall, the relationship of the shear capacity of unreinforced masonry wall and the vertical compressive strain is linear under lateral load; the speed of stiffness degeneration is accelerated after the peak point of the curves, but decrease with the increasing of lateral displacement. As for masonry wall strengthened with steel strips, the shear capacity increases significantly, and shows nonlinear relationship with the cross section area of the steel strips and vertical compression; ductility is improved. Finally, a computational formula of shear capacity based on a lot of parametric analysis is proposed to calculate the sectional dimension of steel strips, and it provides theoretical foundation for establishing thorough design method of masonry wall strengthened with steel strips.

• Periodical: Advanced Materials Research (Volumes 838-841)
• Pages: 284-296
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.838-841.284
• Online since: November 2013
• Authors: Yu Hua Wang, Bei Bei Wang, Pei Chi, Jun Dong*
• Keywords: Diagonal Steel Strip, Finite Element Analysis (FEA), Masonry Wall, Reinforcement, Shear Capacity

References

[1] Junbin Zhang: Study on methods of strengthening existing primary and secondary schools (Kunming university of technology, China 2012) (In Chinese).

[2] GB 50223-2008. Standard for classification of seismic protection of building constructions[S].

[3] Haifeng Bu: Seismic Behavior Experiments of Masonry Wall Rapidly Strengthened using steel strips (Nanjing university of technology, China 2012) (In Chinese).

[4] Guojue Wang: Nonlinear Anti-Seismic Simulation and Analysis of Masonry Structure with Assembly Columns (Chongqing University, China 2010) (In Chinese).

[5] Tuo Lei, Jiang Qian and Chengqing Liu: Structural Engineerings Vol. 24 (2008), p.22 (In Chinese).

[6] Zhenqing Xu: Seismic Performance Analysis of Confined Masonry (Dalian university of technology, China 2012. ) (In Chinese).

[7] Xiaojie Peng, Anlin Yu and Youzhen Fang: Journal of Suzhou University of Science and Technology(Engineering and technology) Vol. 23 (2010), p.40 (In Chinese).

[8] Jingsong Liu and Hongjun Liu: Equipment Manufacturing Technology Vol. 6 (2009), p.69 (In Chinese).

[9] Nina Zheng: Research on Seismic Behavior of Masonry Structures with Fabricated tie-columns (Chongqing University. China 2010) (In Chinese).

[10] Xi Wang: Appropriate repair research on the seismic reinforcement design of primary and middle school buildings (Hunan University. China 2012) (In Chinese).

[11] Junjie Guo: Experimental research on seismic behavior of small-sized hollow concrete block full-sized wall (Tsinghua University. China 2005) (In Chinese).

[12] Xiangshun Zhang, Qian Gu and Shaomin Peng: World Earthquake Engineering Vol. 19 (2003) p.77 (In Chinese).

[13] Wei Zhang: The finite element analysis of experimental results of and research to shear capacities of CFRP strengthened masonry (Wuhan university of technology. China 2007) (In Chinese).

[14] GB 50003-2001. Code for design of masonry structures. (In Chinese).
