Analysis for Floor Slabs of Wall-Slab System

Abstract:

The structure of Wall-slab is composed of slab and shear wall, and only in the outer wall part are the shear wall connected by a coupling beam. The floor and shear wall can bear vertical force and horizontal lateral force together. While under the situation of irregular bearing form shear wall and irregular partition loads, tablet computing becomes an urgent problem. Aiming at this problem, the model which is one layer of floor of Wall system has been used for analysis through the Safe software. In the condition of different thickness of slabs, exploratory results can get about the slab deformations, stresses and reinforcement ratios. The paragraph provides the basis to determine the optimal thickness of plate.

• Periodical: Advanced Materials Research (Volumes 838-841)
• Pages: 551-554
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.838-841.551
• Online since: November 2013
• Authors: Li Ying Zhang, Xiao Dong Yang*, Wen Pan
• Keywords: Floor Stress, Irregular Tablets, Wall-Slab System

References

[1] Zaiyi Chen, Ruikun Hao, Ehua Fang. The feature and the main research results of a prestressed concrete slab-wall tall building system with large bays. [J]. Building science, (1990).

[2] Dongsheng Huang. The analysis and design of the shear wall structure [M]. Beijing: China Water & Power Press, (2006).

[3] Civil King Software Technology co., LTD. SAFE V12 , the design software system of reinforced concrete, prestressed reinforced concrete and floor slab , beam and foundation [M]. (2009).

[4] Code for design of concrete structures GB 50010-2010 [S]. Beijing: China Architecture &Building Press, (2010).

[5] Load code for the design of building structures GB 50009-50009 [S]. Beijing: China Architecture &Building Press, (2012).
