Small Line Segment Interpolation Algorithm for Smoothing Machining

Abstract:

To make machining surface smoothing, a smoothing interpolation algorithm based on small line segments is proposed to meet the special requirements of smoothing machining. The algorithm takes the approach of s-curve acceleration and deceleration control for single tool path, yet between adjacent parallel trajectory adopts linear acceleration and deceleration control. This method enables feed rate between adjacent tool paths to transit continuously and meets the requirement of flexible and smooth machining. The article constructs a mathematical model of relationship among machining precision, maximum feed rate, acceleration, jerk and maximum allowable instantaneous feed rate to assure machining precision and machining efficiency. The model ensures that acceleration of single tool path and feed rate between parallel tool paths is continuous and simultaneously tries its best to enhance machining efficiency. In the end, the experiment result shows that the algorithm can meet the requirement of smoothing machining with an assurance of machining precision.

• Periodical: Advanced Materials Research (Volume 842)
• Pages: 420-426
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.842.420
• Online since: November 2013
• Authors: Xiao Fei Bu, Hu Lin, Liao Mo Zheng, Han Zhang
• Keywords: Interpolation Algorithm, S-Curve Acceleration and Deceleration Control, Smoothing Machining, Velocity Planning

References

[1] Chuan Shi, Peiqing Ye, Kaiming Yang, The Look-ahead Based Adaptive Motion Control for High-Speed Machining of Complicated Contours, Presented at Proceedings of the 2007 IEEE International Symposium on Assembly and Manufacturing. July, 2007, 31~37.

DOI: 10.1109/isam.2007.4288445

[2] Ye Peiqing, Zhao Shenliang. Study on Control Algorithm for Micro-line Continuous Interpolation[J]. China Mechanical Engineering, 2004, 15(15): 1354-1356.

[3] Lv qiang, Zhang hui. Study on the Method of Increasing Turning Velocity Duing CNC Continuous Machining [J]. Manufacturing Technology & Machine Tool, 2008(7): 79-83 [ 5 ] He bo, Luo lei. Smoothing Algorithm for High Speed Machining at Corner[J]. Transaction of Shanghai Jiaotong University, 2008. 42(1): 83-86.

[4] Huang zhihong, Feed speed control of CNC machining tools[D] . Taibei: National Central University, (2002).

[5] Stephen J, Yutkowitz, West C, et al. Apparatus and method for smooth cornering in a motion control system, USA, 6922606[P]. 2004, 07, 26.

[6] Jun Hu, Lingjian Xiao, Yuhan Wang, An optimal feedrate model and solution algorithm for a high-speed machine of small line blocks with look-ahead, International Journal of Advanced Manufacturing Technology, v 28, n 9, April, 2006, 930-935.

DOI: 10.1007/s00170-004-1884-2
