Ti (CN) Precipitation in Ultra-High Strength Ti Micro-Alloyed Steels with 700MPa Yield Strength on TSCR Process

Abstract:

Precipitates in ultra-high strength Ti micro-alloyed strips with 700MPa yield strength on TSCR process and in the thermal simulation experimental specimen are observed via Scanning Electronic Microscope (SEM) and Transmission Electron Microscope (TEM), the results show that: the precipitates in the Ti micro-alloyed cast slab thermal simulation experiment can be divided into three categories: 1) micron-sized liquation TiN, 2) 100-200nm sized TiC formed along original austenite grain boundaries or along the dendrite segregation band, 3) solid precipitated 50-100nm sized TiN. Deformation induced spherical TiC (about 10nm-30nm) homogeneously distributed in the matrix after the austenite deformation .After simulated coiling, dispersed TiC (about 5-15nm ) precipitated from ferrite are found in the specimen. TiN with hundreds of nanometers size are commonly found in Ti micro-alloyed strips in industrial production. Ti₄C₂S₂ and Ti (CN) are complex precipitated, Ti₄C₂S₂ size is less than 30nm; physical and chemical phase analysis shows that the nanosized TiC precipitates are characterized by high volume fraction and small dimensions.

• Periodical: Advanced Materials Research (Volume 842)
• Pages: 61-69
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.842.61
• Online since: November 2013
• Authors: Qi Lin Chen*, Xin Ping Mao, Xin Jun Sun
• Keywords: Precipitation, Thin Slab Casting and Rolling, Ti Micro-Alloyed Steel

References

[1] Kasper R, Zentara N and Herman J C. Steel Research, 1994, 65(7): 279.

[2] Kasper R, Pawelski O. Thermomechnical treatment of direct-charged thin slabs. MENEC Congress 94, Volume 1, Dusseldorf, 1994: 390.

[3] X.P. Mao X.J. Sun Y.L. Kang Z.Y. Lin,J. Zhou. Iron and Steel , 2005；40(9)：65, In Chinese.

[4] X.P. Mao, X. D, Huo, X.J. Sun, Y. Z. Chai, Mater. Proc. Tech. 210(2010) 1660.

[5] Z.Q. Wang, X.P. Mao, Z.G. Yang, X.J. Sun, Q.L. Yong, Z.D. Li and Y.Q. Weng. Mater. Sci. Eng. A, 529(2011), 459.

[6] X.P. Mao. Microalloying Technology on Thin Slab Casting and Direct Rolling Process. Beijing: Metalllurgical industry press, 2008: 17, In Chinese.

[7] X.P. Mao, X.D. Huo, X.J. Sun, Y.L. Kang. Acta metallurgica sinica, 2006, 42(10): 1091, In Chinese.

[8] X.P. Mao X.D. Huo Q.Y. Liu. Iron and Steel Supplement(1), 2006; 41: 109, In Chinese.

[9] X.P. Mao Q.L. Chen D.Y. Zhu. Iron and Steel , 2008; 43(4): 1, In Chinese.

[10] Narita K. Trans ISIJ, 1975, 15: 145.

[11] Kunze J. Steel Research, 1991, 62(10): 430.

[12] Taylor K A. Scripta Metallurgica et Materialia, 1995, 32(1): 7.

[13] Gladman T, Dulieu D, Mcivor I D. MicroAlloying 75: 32.
