Mechanism Design of the Automatic Adjustment of the Number of Inserting Fuses of the Inserting Fuse Machine for Firecracker

Abstract:

Currently, its problems are about feeding more and inserting less fuses at a time, needing triple cooperation of rotary pairs, locations, and low production efficiency. A new type of feed of fuses mechanism was designed, its automatic adjustment of the number of inserting fuses can come out by means of the transmission fit of the trapezoidal axis with the via holes. The axis is a quadrangular prism in the middle and circular cylinders on both sides and the holes are in the middle of the pulling roll wheel pieces. It greatly improves the production efficiency.

• Periodical: Advanced Materials Research (Volume 842)
• Pages: 624-628
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.842.624
• Online since: November 2013
• Authors: Guo Ping Liu, Wei Qiang Wang*, Zhi Yong Cai, Rong Hua Hu
• Keywords: Automatic Adjustment of the Number of Inserting Fuses, Automatic Inserting Fuse Machine for Firecracker, Firecracker, Fuse
