Effect of Variation in Grain Size on High Temperature Creep Test of Fe-Ni-Cr Alloy

Abstract:

Fe-Ni-Cr or known as Incoloy 800H and Haynes HR120 is a solid solution strengthened iron-nickel based superalloy which is extensively used in high temperature and corrosive environment. The effect of grain size in creep strength and creep rate comes through the grain boundary sliding and grain boundaries as barrier mechanism. This paper describes the effect of microstructural variation of Fe-Ni-Cr on the high temperature creep properties. The materials were heat treated at temperature 1050°C and 1200°C followed by water quenching process. The grain size of the samples of Incoloy 800H is 95.47μm for as-received, 122.81μm for solution treated at 1050°C and 380.95μm for solution treated at 1200°C. And the grain size of the samples of Haynes HR120 is 53.45μm for as-received, 61.50μm for solution treated at 1050°C and 158.27μm for solution treated at 1200°C. The creep damage investigation was carried out in the three different grain sizes of Fe-Ni-Cr superalloy at 900°C with stress at 100MPa. Rectangular section forms of specimens are used in the research. In all the tests conducted, the creep curves show primary, secondary and tertiary stages. The creep fracture surface were characterised by using scanning electron microscope. It was found that larger grain size results in lower creep rate for alloy Haynes HR120 but inverse result showed on alloy Incoloy 800H.

You might also be interested in these eBooks

Materials, Industrial, and Manufacturing Engineering Research Advances 1.1

View Preview

Info:

Periodical:

Advanced Materials Research (Volume 845)

Pages:

51-55

DOI:

https://doi.org/10.4028/www.scientific.net/AMR.845.51

Citation:

Cite this paper

Online since:

December 2013

Authors:

Esah Hamzah*, Maureen Mudang, Muhammad Adil Khattak

Keywords:

Fe-Ni-Cr Alloy, Grain Size, Haynes HR120, High Temperature Creep, Incoloy 800H

Export:

RIS, BibTeX

Price:

Permissions CCC:

Request Permissions

Permissions PLS:

Request Permissions

Сopyright:

Citation:

* - Corresponding Author

References

[1] E. Chateau, L. Remy, Oxidation-Assisted Creep Damage in a Wrought Nickel-Based Supperalloy: Experiments and Modelling, Materials Sci. and Engineering A. 527 (2010) 1655-1664.

DOI: 10.1016/j.msea.2009.10.054

Google Scholar

[2] M. P. Tresa, S. Tin, Nickel-Based Superalloys for Advanced Turbine Engines: Chemistry, Microstructure, and Properties, Propulsion and Power. 22 (2006) 361–374.

DOI: 10.2514/1.18239

Google Scholar

[3] X. D. Hui, Y. S. Yang, Z. F. Wang , G. Q. Yuan , X. C. Chen, High temperature creep behavior of in-situ TiC particulate reinforced Fe-Cr-Ni matrix composite, Materials Sci. and Eng. A. 282 (2000) 187–192.

DOI: 10.1016/s0921-5093(99)00751-0

Google Scholar

[4] R. Dehmolaei, M. Shamanian and A. Kermanpur, Microstructural Changes and Mechanical Properties of Incoloy 800 after 15 years service, Materials Characterization. 60 (2009) 246-250.

DOI: 10.1016/j.matchar.2008.08.012

Google Scholar

[5] J. Gan, J.I.C., T.R. Allen, S. Shutthanandan, S. Thevuthasan, Irradiated microstructure of alloy 800H, Journal of Nuclear Materials. 351(1-3) (2006) 223-227.

DOI: 10.1016/j.jnucmat.2006.02.009

Google Scholar

[6] L. Tan, K.S., T.R. Allen, The effect of grain boundary engineering on the oxidation behavior of Incoloy alloy 800H in supercritical water, Journal of Nuclear Materials. 348(3) (2006) 263-271.

DOI: 10.1016/j.jnucmat.2005.09.023

Google Scholar

[7] L.J. Chen, P.K.L., H. Wang, Y.H. He, R.L. McDaniels, L. Jiang, and D.L.K. B. Yang, Cyclic deformation behavior of Haynes HR-120 superalloy under low-cycle fatigue loading, Machanics of Materials. 36 (2004) 85-98.

DOI: 10.1016/s0167-6636(03)00033-4

Google Scholar

[8] Y.H. He, L.J.C., P.K. Liaw, R.L. McDaniels, C.R. Brooks, R.R. Seeley, and D.L. Klarstrom, Lowcycle fatigue behavior of Haynes HR120 alloy. I. J of Fatigue. 24 (2002) 931-942.

DOI: 10.1016/s0142-1123(02)00009-9

Google Scholar

[9] H. Wang, L.J., Y.H. He, L.J. Chen, P.K. Liaw, R.R. Seeley, D.L. Klarstrom, Infrared Imaging during Low-Cycle Fatigue of HR-120 Alloy, Metallurgical and Materials Transsactions A. 33A (2002) 1287-1292.

DOI: 10.1007/s11661-002-0231-1

Google Scholar

[10] E. Chateau, L. Remy, Oxidation-Assisted Creep Damage in a Wrought Nickel-Based Supperalloy: Experiments and Modelling, Materials Sci. and Engineering A. 527 (2010) 1655-1664.

DOI: 10.1016/j.msea.2009.10.054

Google Scholar

[11] Y. S. Lee, D. W. Kim, D. Y. Lee and W. S. Ryu, Effect of Grain Size on Creep Properties of Type 316N Stainless Steel, Metals and Meterials International. 7 (2001) 107-114.

DOI: 10.1007/bf03026948

Google Scholar

[12] R. Voicu, J. Lacaze, E. Andrieu, D. Poquillon, and J. Furtado, Creep and Tensile Behaviour of Austenitic Fe–Cr–Ni Stainless Steels, Materials Sci. and Engineering A. 510-511 (2009) 185-189.

DOI: 10.1016/j.msea.2008.04.098

Google Scholar
