Application Situation of Distributed Optical Fiber Temperature Measurement Technology in Power System

Abstract:

Temperature is an important operating parameter of electrical equipment, electrical equipment operating condition obtained by monitoring the temperature information has become research focus for power system fault prediction and diagnosis^[1-. Distributed fiber optic temperature measurement system is a method for real-time measurement of the spatial distribution of temperature field sensing system. The system uses optical time domain reflectometer (OTDR) and laser Raman spectroscopy, amplifies temperature information and processes signal from wavelength division multiplexer and optical detectors, then the temperature information is displayed in real time^[4-. Distributed fiber optic temperature measurement technology has several characteristics with insulation, anti-electromagnetic interference, resistance to high voltage, resistance to chemical corrosion, and security^[6-. This article outlines the basic power system temperature monitoring content, studies the current distributed optical fiber temperature measurement technology applications in power system and prospects for its development trend.

• Periodical: Advanced Materials Research (Volumes 846-847)
• Pages: 918-921
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.846-847.918
• Online since: November 2013
• Authors: Xiao Juan Li*, Zhi Yong Xie, Xiao Bin Liang, Xian Long Zhao, Ze Gui Chen
• Keywords: Distributed Optical Fiber, Power System, Temperature Measurement

References

[1] H.Z. Huang, Z.S. Yang and S.G. Xu: Development of Optical Fiber Sensors and Their Application in Power Systems[J]. Advanced Technology of Electrical Engineering and Energy, 1990, 3: 27-33.

[2] Y. Zhang and J. Zhang: Current Status and Developing Trend of Distributed Optical Fiber Temperature Sensor[J]. Instrument Technique and Sensor, 2007, 8: 1-4.

[3] M.K. He, P.Z. Zhang and Y.L. Li: Application of distributed temperature sensing technology for power equipment monitoring[J]．Electrical Equipment, 2007, 8(10): 30-32.

[4] A.J. Rogers: Distributed optical fiber sensors for the measurement of pressure, strain and temperature [J ]. Journal of the Institution of Electronic and Radio Engineers. 1998, (7) : 3- 22.

[5] A.J. Rogers: Optical measurement of current and voltage on power system [J ]. IEEE Journal of Electric Power Application. 1999, 2(4) : 20- 124.

[6] D.W. Liang and S.L. Huang: Research Status and Development of Distributed Optical-Fiber Temperature Sensor[J]. Journal of Applied Optics, 1991, 12（3): 1-6.

[7] D.B. Su: Present Status of Development of Optical Fiber Temperature Sensor[J]. Journal of Transducer Technology, 1995, 6: 1-6.

[8] Y. Zhang and J. Zhang: Current Status and Developing Trend of Distributed Optical Fiber Temperature Sensor[J]. Instrument Technique and Sensor, 2007, 8: 1-4.

[9] J.F. Wang and Z.Y. Zhang: Research of a New Temperature Measure Principle of Distributed Optical Fiber Temperature Sensors[J]. Journal of China Jiliang University, 2006, 17(1): 25-28.

[10] T. Tozaki, M. Kata and K. Inada: Raman Backscattering Characteristics of the Optical Fiber and Distributed Temperature Sensor[M]. Fujikura Technical Review, 1990: 25-30.

[11] K.Y. Lee and J.P. Velas: Development of an Intelligent Monitoring System with High Temperature Distributed Fiber-optic Sensor for Fossil-fuel Power Plants[M]. IEEE Power Engineering Society General Meeting, 2004: 1989-(1994).

DOI: 10.1109/pes.2004.1373225

[12] Q.M. Meng. Application on Temperature Monitoring for HV Switches Based on Fiber-Optic Sensors[J]. Sensor World, 2005, 7: 19-22.

[13] X.H. Mao, Q.P. Shi: Application of Optical Fiber Sensor to Security Monitoring of Electrical Devices[J]. Metrology & Measurement Technology, 2007, 27(5): 20-23.

[14] T. Nishimoto, T. Miyahara and H. Takehana: Development of 66 kV XLPE Submarine Cable Using Optical Fiber as a Mechanical Damage-detection Sensor[J]. IEEE Trans on Power Delivery, 1995, 10(4): 1711-1737.

DOI: 10.1109/61.473390
