A Convenient Method for Calculating Internal Force of Rod for Tower Crane

Abstract:

This paper made an assumption which considered the structure of tower crane as truss structure and equated the complex spatial structure of tower body under multi-loads to single planar truss structure. The calculation model of internal force of rods was built. The calculation formulas of four types of trellis tower mast configuration commonly used were derived. The result based on the real project given by the calculation formulas agreed with the result given by the finite element software. These explicitly expressed formulas were simple and easy to calculate by hand. An accurate and efficient method to calculate internal force of rods of tower crane was provided.

• Periodical: Advanced Materials Research (Volume 853)
• Pages: 541-546
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.853.541
• Online since: December 2013
• Authors: Yuan Xue*, Da Qi Wu, Bin Kou, Nian Li Lu
• Keywords: Equivalent Load, Internal Force of Rod, Tower Body, Tower Crane

References

[1] Fan Jihua and Zhang Dingguo. B-spline interpolation method for the dynamics of rotating cantilever beam [J]. Chinese Journal of Mechanical Engineering. 12(2012), pp.59-64.

DOI: 10.3901/jme.2012.23.059

[2] Lu Nianli and Sun Jiachao. Jan. Fast calculation of the forces of boom brace of horizontal boom with two lifting points for tower cranes under complex loads[J]. Construction Machinery. 11(2013), pp.75-77.

[3] Li Lei and Song Shijun. Jan. Simple calculating method of internal force of attached bar for tower crane with 4 attached bars[J]. Construction Machinery. 11(2013), pp.83-86.

[4] Chen Weizhang. Metal Structure of Hoisting Machinery, M. China Communications Press(1985).

[5] Xue Yuan and Lu Nianli. An efficient method for calculating of torsion stiffness of trellis tower mast[J] . Construction Machinery. 6(2004), pp.83-86.
