Optimization of Process Parameters of Diffusing Bonding of Titanium with Titanium and Titanium with Copper

Abstract:

The diffusion bonding of Ti to Ti, Ti-Cu alloy at different temperatures ranging from 673 K to 923 K under an applied stress of 100 MPa for 1 h was studied. The observation of the microstructure reveals that sound joints between the Ti-Ti and dissimilar titanium/Copper metals sheet were successfully joined by diffusion bonding process. Ti-Cu alloy without any pores or cracks can be achieved through diffusion bonding at temperatures over 873 K under the applied stress of 100 MPa for 1 h. The bond is composed of the zones, and its width increases with the increase of bonding temperature. The Micro hardness at the interface of joints bonded under different conditions was evaluated through Micro hardness testing and the fracture mode was analyzed by SEM observation.

• Periodical: Advanced Materials Research (Volume 856)
• Pages: 153-158
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.856.153
• Online since: December 2013
• Authors: Kasigavi Chandrappa, Joel Hemanth
• Keywords: Copper Alloy Sheet, Diffusion Bonding, Hot Press, Microhardness, Roughness SEM, Surface, Titanium Alloy Sheet

References

[1] LIN J G, YU G S, HUANG Z, W G Q. A novel approach to the solid bonding of a TiAl alloy [Jl. J Mater Sci Letter, 2001, 20(18): 1671-1673.

[2] An investigation of the fracture behaviour of diffusion-bonded Ti6Al4V/TiC/10p by Antonio A.M. da Silva a, Jorge F. dos Santos a, *, Telmo R. Strohaecker, Composites Science and Technology 66 (2006) 2063–(2068).

DOI: 10.1016/j.compscitech.2005.12.018

[3] 3. 091 – Introduction to Solid State Chemistry by Shermon, P. G.

[4] CAM 4 KOCAK M. Diffusion bonding of investment cast y-TL4I [Jl. J Mater Sci], 1989, 41(7): 1-5.

[4] KIM Y W. Intermetallic alloys based on gamma titanium aluminide [Jl. JOM], JOM, 1989, 41(7): 24-30.

DOI: 10.1007/bf03220267

[5] KIM Y W, DIMlDUK D M. Progress in the understanding of gamma titanium aluminides[J], 1991, 43 (8): 40-47.

[6] HE be-hui, HUANG Bai-yun, ZHOU Ke-cao, OU Wei-pei, CHENG Xiaoqun. Influence of microstructure of Ti-Al based alloy on the mechanical properties at elevated temperature [J]. The Chinese Journal of Non ferrous Metals, 1997, 7(1): 75-79. (in Chinese).

[7] LIN Jian-guo, ZHANG Yong-gang, CHEN Changqi. Effects of lamellar boundaries on creep behaviour of pst crystals of TiAl alloys [Jl. Trans Nonferrous Met Soc China], 8(4): 562-566.

[8] Equations from an investigation of the fracture behavior of diffusion-bonded Ti6Al4V/TiC/10p, from 2-8.

[9] Equations from an investigation of the fracture behavior of diffusion-bonded Ti6Al4V/TiC/10p, from 2-8.
