Microstructural Study of Reduced Malaysian Ilmenite by Carbothermal Reduction and Nitridation in Nitrogen Atmosphere

Abstract:

The reduction of Malaysia Ilmenite (FeTiO₃) with coal by carbothermal reduction under N₂ atmosphere was studied. Characterization of raw materials was done by XRD, XRF, Optical Microscopy (OM) and SEM analysis. Isothermal experiments were carried out using the pellets in a horizontal tube reactor with continuously flowing gas. From the experiments, 0-10 wt. % of FeCl₃ was added in the ilmenite-coal mixtures before reduction. The mixture was reduced at 1100°C for 60, 120 and 180 minutes. The addition of FeCl₃ acted as a catalyst and increased the rate of reduction. The microstructures of the reduced sample were porous with the addition of FeCl₃. Furthermore, defects were observed due to increase release of Cl₂ and CO during reduction. FeCl₃ acted as catalyst in the gasification of coal by the Boudouard reaction. SEM analysis indicates that the microstructure of the particles was coarsened due to the addition of catalyst. Besides that, there was less agglomeration of metallic iron particles at higher addition of FeCl₃. The effect of FeCl₃ on the morphology iron was the nucleation of microscopic iron rich zones in the reduced sample. Keywords: Carbothermal Reduction, Iron Chloride, Malaysian Ilmenite, Nitridation, Titanium Oxycarbonitride.

• Periodical: Advanced Materials Research (Volume 858)
• Pages: 265-271
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.858.265
• Online since: November 2013
• Authors: Aishah Syed Salim Sharifah, Hanizam Shah Saidin, Norlia Baharun, S.A. Rezan, Hussin Hashim
• Keywords: Carbothermal Reduction, Iron Chloride, Malaysian Ilmenite, Nitridation, Titanium Oxycarbonitride

References

[1] Froes, F.H.S., Titanium, in Encyclopedia of Materials Science and Engineering, P. Bridenbaugh, Editor. 2001, Elsevier: Oxford, UK. pp.9361-9374.

[2] Francis, A.A. and El-Midany, A.A., An Assessment of the Carbothermic Reduction of Ilmenite Ore by Statistical Design. Journal of Materials Processing Technology, 2007. 199: pp.1-14.

DOI: 10.1016/j.jmatprotec.2007.08.031

[3] Wang, Y. and Z. Yuan, Reductive kinetics of the reaction between a natural ilmenite and carbon. International Journal of Mineral Processing, 2006. 81(3): pp.133-140.

DOI: 10.1016/j.minpro.2006.07.010

[4] Rezan, S.A., G. Zhang, and O. Ostrovski, Carbothermal Reduction and Nitridation of Ilmenite Concentrates. International Steel Institute of Japan (ISIJ), (2012).

DOI: 10.2355/isijinternational.52.363

[5] Sharifah Aishah, Sheikh A. Rezan, and H. Hussin, Synthesis of Titanium Oxycarbonitride by Carbothermal Reduction and Nitridation of Malaysian Ilmenite in Nitrogen Atmosphere, in 4th AUN/SEED-Net Regional Conference on Natural Resources and Materials (RC-NRM) and MetCon 2011. 2011, Aunseednet: Subic Bay, Philipines. p.16.

DOI: 10.4028/www.scientific.net/amr.858.265

[6] Rezan Sheikh, A., G. Zhang, and O. Ostrovski, Phase Development in Carbothermal Reduction and Nitridation of Ilmenite Concentrates. High Temperature Material Process, 2012. 31(4-5): p.381.

DOI: 10.1515/htmp-2012-0070

[7] Rezan, S.A., Adipuri, A., Zhang, G., and O. Ostrovski. Carbothermal Reduction and Nitridation of Ilmenite Concentrates and Chlorination of the Reduced Samples. in XXV International Mineral Processing Congress (IMPC 2010). 2010. Brisbane, Australia, (2010).

DOI: 10.2355/isijinternational.52.363

[8] Gupta, S., V. Rajakumar, and P. Grieveson, Kinetics of reduction of ilmenite with graphite at 1000 to 1100°C. Metallurgical Transactions B, 1987. 18(4): pp.713-718.

DOI: 10.1007/bf02672888

[9] Dewan, M., G. Zhang, and O. Ostrovski, Carbothermal Reduction of a Primary Ilmenite Concentrate in Different Gas Atmospheres. Metallurgical and Materials Transactions B, 2010. 41(1): pp.182-192.

DOI: 10.1007/s11663-009-9308-1
