Motion Characteristics and Influence Factors of Piston Assembly in a Compression-Ignition Hydraulic Free-Piston Engine

Abstract:

The advantages and basic structure of hydraulic free-piston engine (HFPE) were presented. And the operation principle of a single piston compression-ignition HFPE was analyzed. Based on the basic theory of thermodynamics, hydraulic fluid mechanics and dynamics, the system simulation model for a single-piston compression-ignition HFPE was established in the environment of MATLAB/SIMULINK. The simulation results, which accord with the related literature data, indicate that the asymmetric characteristics of piston motion in the entire cycle are very obvious, the compression stroke duration is longer than the expansion stroke, the time at around the top dead center (TDC) is short. The piston assembly motion is a process when the energy balance is fulfilled, and some factors must be taken into account for design optimization, such as the piston assembly mass, compression accumulator pressure, fuel injection timing and fuel injection quantity.

• Periodical: Advanced Materials Research (Volumes 860-863)
• Pages: 1761-1765
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.860-863.1761
• Online since: December 2013
• Authors: Ying Xiao Yu, Zhao Cheng Yuan, Jia Yi Ma*, Shi Yu Li
• Keywords: Asymmetric Motion, Energy Balance, Hydraulic Free-Piston Engine, Piston Assembly

References

[1] S. Tikkanen, M. Lammila, et al, First Cycles of the Dual Hydraulic Free Piston Engine, SAE paper, 2000-01-2546.

DOI: 10.4271/2000-01-2546

[2] Tóth-Nagy, N. N. Clark, The Linear Engine in 2004, SAE paper, 2005-01-2140.

[3] Peter A.J. Achten, Johan P.J., et al, Horsepower with brains: The design of the CHIRON Free Piston Engine, SAE paper, 2000-01-2545.

DOI: 10.4271/2000-01-2545

[4] R. Mikalsen, A.P. Roskilly, Applied Energy, Vol 87, Jan. (2010).

[5] J. Fredriksson, I. Denbratt, Simulation of a Two-Stroke Free Piston Engine, SAE paper, 2004-01-1871.

DOI: 10.4271/2004-01-1871

[6] R. Mikalsen, A.P. Roskilly, Applied Thermal Engineering, Vol 27, Oct. (2007).

[7] M. Mugele, J. Tribulowski, Analysis of Gas Exchange and Combustion Process in a Small Two-Stroke Gasoline, SAE paper, 2001-01-3602.

DOI: 10.4271/2001-01-3602

[8] B.V.V.S.U. Prasad, C.S. Sharma, et al. Applied Energy, Vol 88, Jul. (2011).

[9] R. Mikalsen, A.P. Roskilly, Applied Energy, Vol 86, (2009).
