Improving the Transfer Efficiency of a Wireless Energy Transfer System Using Multiple Coils

Abstract:

This study is to suggest using multiple transmission coils to improve the energy transfer efficiency of a wireless energy transfer (WET) system which aims to power electronic appliances such mobile phones, labtops, iPads, etc, without using cables. The original WET system consists of a large room-size transmission coil transferring energy wirelessly to a small receiver coil built insider an electronic appliance. The newly proposed system is to replace the single transmission coil with 3 orthogonally aligned transmission coils. The aim is to create a multi-oriented magnetic field so that energy transfer efficiency will be relatively more stable when the receiver coil changes in orientation. Our simulation results show that at some worse-situation orientations of the receiver coil, the increase in transfer efficiency is many folds, from 0.4% in the worse situation to a 2.75% after using the multiple-transmission-coil method. This, to some extent, safeguards the wireless charging process from a large power drop to a much smaller power drop during possible random motions of the receiver. But, on the other hand, the improvements obtained from the proposed system in the normal high-efficiency situations are not very significant.

• Periodical: Advanced Materials Research (Volumes 860-863)
• Pages: 2275-2278
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.860-863.2275
• Online since: December 2013
• Authors: Hon Tat Hui*, Shi Pu, Marcus Choo Ann Loong
• Keywords: Circuit Matching, Energy Transfer Efficiency, Magnetic-Field Coupled Resonance, Wireless Energy Transfer

References

[1] A. Kurs, A. Karalis, R. Moffatt, J. D. Joannopoulos, P. Fisher, and M. Soljacic, Wireless power transfer via strongly coupled magnetic resonances, Science, vol. 317, no. 5834, p.83–86, Jul.

DOI: 10.1126/science.1143254

[2] K. Hatanaka, F. Sato, H. Matsuki, S. Kikuchi, J. Murakami, M. Kawase, and T. Satoh, Power transmission of a desk with a cord-free power supply, IEEE Trans. Magn., vol. 38, no. 5, pp.3329-3331, Sep. (2002).

DOI: 10.1109/tmag.2002.803120

[3] Y. Hori, Looking at Cars 100 Years in the Future, Proceedings of the 2013 IEEE.

[4] Yuan, Q., Qiang, C., Long, L., and Sawaya, K. (2010). Numerical Analysis on Transmission Efficiency of Evanescent Resonant Coupling Wireless Power Transfer System. IEEE Transactions on Antennas and Propagation, 58(5), 1751-1758.

DOI: 10.1109/tap.2010.2044321

[5] http: /www. feko. info.
