Thermal Analysis and Design of the Cryogenic System for 12 MW Offshore Superconducting Wind Turbine

Abstract:

Applied superconductivity technology has been thought of being utilized in manufacturing large capacity wind turbines for several years. It is regarded as the only way to minify the volume and mass for large electric motors. Cryogenic system for the generator is fatally important, to create the necessary low temperature maintaining field windings superconducting state. Aiming at designing a reliable cryogenic system for large capacity as 12 MW superconducting generators field winding, in this paper, thermal numerical calculation and analysis for the superconducting coil with cold shield with multilayer insulation (MLI) are done, a dynamic model is established with finite element method (FEM) to verify the previous analysis. Optimization is also done to reduce the thermal loss. Proposal for the numbers of Cryocoolers needed and their layout in generator are given.

• Periodical: Advanced Materials Research (Volumes 860-863)
• Pages: 242-248
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.860-863.242
• Online since: December 2013
• Authors: Xiao Yu Li*, Jie He, Li Ren, Meng Song, Kun Nan Cao, Da Da Wang, Jing Dong Li, Shi Feng Shen
• Keywords: Cryogenic System, Field Winding, Low Temperature Superconductor, Wind Turbine (WT)

References

[1] Anbin C., Xiaokun L., Fengyu X., Jiwei C., and Liyi L., Design of the Cryogenic System for a 400 kW Experimental HTS Synchronous Motor. IEEE Transaction on Applied Superconductivity. (2010) 20, 2062-(2065).

DOI: 10.1109/tasc.2009.2039206

[2] Hongtao R., Yushun B., Xiaoping W., and Ling X., AC Loss at Low Frequency for NbTi Multi-conductor wire. Cryogenics and Superconductivity: (1982) 3, 68-71.

[3] Li R., Yuejin T., Hansong S., Jingdong L., Jing S., Bin W., and Shijie C., Study on Heat Leakage of Current Leads of 300kVA HTS Transformer. Physica C. (2006) 442, 39-44.

DOI: 10.1016/j.physc.2006.04.018
