Investigation of Performance Advantages of Internal Circulation Two-Platen Injection Molding Machine

Abstract:

The performance advantages of the newly full-hydraulic internal circulation two-platen injection molding machine were investigated deeply and comprehensively. The application prospects were also forecasted. Thanks to the use of internal circulation cylinders in the injection molding machine, the hydraulic system is greatly simplified. Mold-moving and mold-locking are actuated by different cylinders respectively which not only balance the force and velocity but obtain excellent mold-locking properties and high molding stability. The injection molding machine was equipped with servomotor which drives quantified pump in order to save energy and lower noise. The newly full-hydraulic internal circulation two-platen injection molding machine will be the next generation injection molding machine.

• Periodical: Advanced Materials Research (Volumes 87-88)
• Pages: 27-30
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.87-88.27
• Online since: December 2009
• Authors: Zhi Wei Jiao, Peng Cheng Xie, Zhi Yun Yan, Wei Min Yang, Xing Tian Wang
• Keywords: Clamping Unit, Internal Circulation, Two-Platen Injection Molding Machine

References

[1] Sheng-liang Zhang: Light Industry Machinery Vol. XX(2002), pp.15-18.

[2] Huang Buming: Engineering Plastics Application Vol. 6(2000), pp.32-35.

[3] Xingtian Wang, CN Patent 200520145200. 2（2007）.

[4] YANG Wei-min, GAO Shi-quan: Use and maintenance manual of injection molding machines(China Machine Press, Beijing 2003).
