The Unsteady Flow and Forced Response for a Variable Nozzle Turbine

Abstract:

Variable nozzle turbine (VNT) has become a popular technology for diesel application. While one of the major challenges for VNT is resonant vibration due to the fluctuating pressure in unsteady flow. Both the leakage flow forms inside the nozzle clearances and the shock produces under small nozzle openings increase the flow unsteadiness inside downstream rotor tunnel. In this paper, the unsteady simulation of the turbine was conducted to investigate the effects of nozzle clearances and openings on the transient load fluctuation of the blades. Then a finite element model of turbine wheel was built and blade forced response was simulated with harmonic analysis. The results showed that the decrease of nozzle opening would intensify rotor vibration and increase the blade dynamic stress. The simulation of blade resonance showed that the 1st order resonance located at the blade trailing edge while the 2nd order resonance happened at the leading edge, which was consistent with the blade actual crack.

• Periodical: Advanced Materials Research (Volume 871)
• Pages: 296-303
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.871.296
• Online since: December 2013
• Authors: Yi Xiong Liu*, Da Zhong Lao, Yin Hong Liu, Ce Yang, Chao Chen Ma
• Keywords: Forced Response, Harmonic Vibration, Unsteady Flow, Variable Nozzle Turbine

References

[1] Tom Heuer, Marc Gugau, Achim Klein, et al. An Analytical Approach to Support High Cycle Fatigue Validation for Turbocharger Turbine Stages[C]. Berlin: ASME Turbo Expo 2008, 723-732.

DOI: 10.1115/gt2008-50764

[2] Tamaki, H, Goto, S, Unno, M, et al. The Effect of Clearance Flow of Variable Nozzle on Radial Turbine Performance [C]. Berlin: ASME Turbo Expo (2008).

[3] Hu Liangjun, Yang Ce, Sun Harold, et al. Numerical Analysis of Nozzle Clearance Effect on Turbine Performance [J]. Chinese Journal of Mechanical Engineering, 2011, 24(4), 618-625.

[4] Hu Liangjun, Sun Harold, Jianwen Yi, et al. Investigation of Nozzle Clearance Effects on a Radial Turbine: Aerodynamic Performance and Forced Response[C]. SAE Technical Papers, 2013, vol2.

DOI: 10.4271/2013-01-0918

[5] Chen H. Turbine wheel design for Garrett Advanced Variable Geometry Turbines for Commercial Vehicle Applications[C]. Proc. 8th international conference of turbochargers and turbocharging, 2006, 317-327.

DOI: 10.1016/b978-1-84569-174-5.50027-0

[6] Doorly D.J., Oldfield, M.L.G. Kawakubo T. Unsteady Rotor-Stator Interaction of a Radial-Inflow Turbine with Variable Nozzle Vanes[C]. Glasgow: ASME Turbo Expo 2010, 2075-(2084).

DOI: 10.1115/gt2010-23677

[7] Simulation of the Effects of Shock Wave Passing on a Turbine Rotor Blade[J]. Journal of Engineering for Gas Turbines and Power, 1985, vol107, 998-1006.

DOI: 10.1115/1.3239847

[8] T. Kreuz-Ihli, D. Filsinger. Numerical and Experimental Study of Unsteady Flow Field and Vibration in Radial Inflow Turbines[J]. Journal of Turbomachinery, 2000, 122(2), 247-254.

DOI: 10.1115/1.555441

[9] Hans-Jorge B., Achmed S. Aerodynamic Excitation of blade Vibrations in Radial Turbines[J]. Research vibration, 2013, vol74, 48-54.
