Design and Simulation Study of a Certain Landing Gear Loading Simulation System

Abstract:

The landing gear ground loading tests is a vital part before flight. As the motion of landing gear is three-dimensional motion,the traditional loading method cannot effectively simulate the pneumatic load on the ground. In order to simulate the load in the process of retraction/extension, a loading simulation system is proposed, including retractile system, position follow-up system and force servo loading system. This paper analyzes retraction/extension mechanism of the landing gear and builds up its mathematical model. A co-simulation model is developed in which the hydraulic system model and control system are built in software AMESim, the mechanical system of test platform model is built in software ADAMS. The results of the simulation confirm that the loading simulation system is feasible and provide the basis for building hardware platform.

• Periodical: Advanced Materials Research (Volume 871)
• Pages: 69-76
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.871.69
• Online since: December 2013
• Authors: Jun Gong Ma*, Zhong Zhi Wu, Hao Ran Guo, Jia Li
• Keywords: Co-Simulation, Loading, Three-Dimensional Motion

References

[1] Pritchard, Jocelyn. Overview of landing gear dynamics., Journal of aircraft 38. 1 (2001): 130-137.

[2] McGehee, John R., and Huey D. Carden. Analytical Investigation of the Landing Dynamics of a Large Airplane with a Load-Control System in the Main Landing Gear. No. NASA-L-13250. NATIONAL AERONAUTICS AND SPACE ADMINISTRATION HAMPTON VA LANGLEY RESEARCH CENTER, (1979).

[3] Xingmin Yu. Design and Implement of Electro-hydraulic Servo Loading System for Landing Gear, Chinese Hydraulics and Pneumatics 9 (2012): 007.

[4] Li Wei, Likang Yang, Caijun Xue. Hydraulic System for Landing-gear Retraction Dynamic Loading Test, Machine Tool & Hydraulic 38. 019 (2010): 53-57.

[5] Fang Qiang, Research on Design Method for Passive Torque Servo Control System and Its Application [D]. Diss. Harbin: Harbin Institute of Technology, (2006).

[6] Jian-jun Shen, Long Liu, Hongcai Tang, Simulation and analysis on vibratory hydraulic system on tandem rollers using AMEsim and ADAMS, Chinese Journal of Construction Machinery ISTIC 7. 1 (2009).

[7] Yongling Fu, Xiaoye Qi, LMS Imagine. Lab AMESim(Advanced Modleing Environment for Simulation of engineering systems), BeiJing(2011).

[8] ADAMS interface, AMEHelp (2010).

[9] AMESim and Simulink Manual, AMEHelp (2010).
