A Localization Model for Snubber Machining of Precision Forging Blade

Abstract:

The compressor blades of aero-engines are usually produced with precision forging technology to get net-shape free-form surface of the blades. Due to the complex shape of blade snubber, it’s very difficult to get net-shape for it. While, there are still lots of raw material around it, further multi-axis machining is needed. However, without raw material left on blade surfaces, it is very difficult and skill-dependent to design special fixture to localize the blade with its net-shape free-form surface for multi-axis milling. In order to mill blade snubber with high accuracy, a mathematical model for localization precision forging blade with snubber is proposed in this paper. According to the processing characteristic of precision forging blades, a point set selection method based on the CAD model is proposed. In this method, localization transform parameter is obtained by using SVD (Singular Value Decomlocalizing), and solving process is completed by employing iterative nearest point (ICP) algorithm. Finally, a machining simulation experiment is carried out to validate the effectiveness of the proposed method.

• Periodical: Advanced Materials Research (Volumes 875-877)
• Pages: 1127-1132
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.875-877.1127
• Online since: February 2014
• Authors: Jian Hua Yang, Ding Hua Zhang, Bao Hai Wu, Ying Zhang
• Keywords: Iterative Nearest Point (ICP), Localization Model, Point Set Selection Method, Snubber Machining

References

[1] Shan D. B, Xu W. C and Lu Y: Study on precision forging technology for a complex-shaped light alloy forging. Journal of Materials Processing Technology. 151(2004) 289-293.

DOI: 10.1016/j.jmatprotec.2004.04.075

[2] S. Yuwen, W. Xiaoming and G. Dongming: Machining localization and quality evaluation of parts with sculptured surfaces using SQP method. The International Journal of Advanced Manufacturing Technology. 41(2009) 1131-1139.

DOI: 10.1007/s00170-008-1673-4

[3] Li Z. X, Gou JB and Chu Y. X: Geometric algorithms for workpiece localization. IEEE Transactions on Robotics and Automation. 14(1998) 864–878.

DOI: 10.1109/70.736771

[4] Xiong Z, Li Z: On the discrete symmetric localization problem. International Journal of Machine Tools and Manufacture. 43(2003) 863–870.

DOI: 10.1016/s0890-6955(03)00079-8

[5] Chatelain J. F, Fortin C: A balancing technique for optimal blank part machining. Precision Engineering. 25(2001) 13-23.

DOI: 10.1016/s0141-6359(00)00050-7

[6] Chatelain J. F: Alevel-based optimization algorithm for complex part localization. Precision Engineering. (2005) 197-207.

DOI: 10.1016/j.precisioneng.2004.07.002

[7] Y. Sijie, Z. Yunfei, and P. Fangyu: Research on the localization of the workpieces with large sculptured surfaces in NC machining. The International Journal of Advanced Manufacturing Technology 23(2004)429-435.

DOI: 10.1007/s00170-003-1897-2

[8] Zhang D. H, Zhang Y and Wu B. H: Application of Adaptive Machining Technology in Blisk Manufacturing. Aeronautical Manufacturing Technology. 13(2008)51-55.

[9] Xiong Z. H, LI Z. X: Error compensation of workpiece localization. IEEE International Conference on Robotics & Automation. 3 (2001) 2249-2254.
