Stamp Forming of Polypropylene Based Polymer-Metal Laminates: The Effect of Process Parameters on Spring Back

Abstract:

This paper investigates the effect of process parameters such as Blank Holder Force (BHF) and Feed Rate, on the spring back behavior of a polymer metal laminate (PML) system comprised of aluminum and polypropylene. Specimens were formed over a hemispherical punch in stamp forming process. A novel real time strain measuring system, ARAMIS, was employed to capture the strain evolution during forming. The results of this work indicate that both BHF and feed-rate exert influence in PML spring back behavior. Fundamental correlation between strain evolution during spring back and the shape of the finished part will be presented. A major finding from this work is that aluminum dominates the spring back behavior of PML in stamp forming.

• Periodical: Advanced Materials Research (Volumes 875-877)
• Pages: 423-427
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.875-877.423
• Online since: February 2014
• Authors: Wen Tian Wang, Sudharshan Venkatesan, Anthony Sexton, Shankar Kalyanasundaram
• Keywords: Polymer Metal Laminate (PML), Springback, Stamp Forming

References

[1] Lutz et al. 1986, High heat metal polymer laminate, US Patent 4, 601, 941.

[2] CK Chao, CH, Liu, HJ Wu. 1993. A study of the stretching process of steel–polymer–steel laminate. , Journal of Materials Processing Technology. 155-172.

DOI: 10.1016/0924-0136(94)90484-7

[3] R. Kopp, M. Nutzmann, J. Van Santen. 2005. Formability of lightweight, vibration damping and medium perfused sandwich sheets, analysis through practical experiments and FEM simulations. In: Thomsen OT et al., editors. Sandwich structures 7: advancing with sandwich structures and materials. Springer; 2005. p.723.

DOI: 10.1007/1-4020-3848-8_73

[4] CA. Queener, RJ. De Anglelis. 1957 Elastic spring back and residual stresses in sheet metal formed by bending. , Trans ASME ; 61: 757-68.

[5] L. Mosse W. Cantwell M.J. Cardew-Hall P. Compston and S. Kalyanasundaram 2006 The influence of process variables on the formability of fibre-metal laminates, Journal of Material Processing Technology, vol. 172, pp.163-168.

DOI: 10.1016/j.jmatprotec.2005.09.002

[6] A. Sexton W. Cantwell and S. Kalyanasundaram 2012 Stretch forming studies on fibre metal laminate based on a self-reinforcing polypropylene composite, Composite Structures, vol. 94, pp.431-437.

DOI: 10.1016/j.compstruct.2011.08.004

[7] L. Mosse W. Cantwell M.J. Cardew-Hall P. Compston and S. Kalyanasundaram 2005 Effect of process temperature on the formability of fibre-metal laminates, Composites Part A: Applied Science and Manufacturing, vol. 36, no. 8, pp.1158-66.

DOI: 10.1016/j.compositesa.2005.01.009

[8] J. Gresham W. Cantwell M.J. Cardew-Hall P. Compston and S. Kalyanasundaram 2006 Drawing behaviour of Metal-Composite sandwich structures, Composite Structures, vol. 75, no. 1-4, pp.305-312.

DOI: 10.1016/j.compstruct.2006.04.010

[9] R. Hino, Y. Goto, F. Yoshida. 2003 Springback of sheet metal laminates in draw-bending., The journal of Materials Processing Technology 341-347.

DOI: 10.1016/s0924-0136(03)00541-7

[10] M. H Parsa et al. 2010 Experimental and finite element study on the spring back of double curved aluminium/polypropylene/aluminium sandwich sheet., Materials and Design 4174-4183.

DOI: 10.1016/j.matdes.2010.04.024

[11] J. R Cho et al. 2003. Finite element investigation on spring-back characteristics in sheet metal U-bending process., The Journal of Materials Processing Technology. 109-116.

DOI: 10.1016/s0924-0136(03)00163-8

[12] L. Mosse. 2005, Stamp forming of polypropylene based fibre-metal laminates: The effect of process variables on formability., The Journal of Materials Processing Technology. 163-168.

DOI: 10.1016/j.jmatprotec.2005.09.002

[13] C. Morrow, S. Dharmalingam, S. Venkatesan, S. Kalyanasundaram, Stretch forming studies on thermoplastic composite, In: Proceedings of 6th Australiasian congress on applied mechanics, Perth, Australia December, (2010).
