Study on Distribution Performance of a New Oil-Air Distributor in Oil-Air Lubrication System

Abstract:

The fluid domain model of a new oil-air distributor in oil-air lubrication system is built and the phase distribution of oil and air two-phase flow on distribution interface is simulated based on the CFD model in Fluent, the mass flow rate of oil and air are collected from three different cross sections when the structures of oil-air guidance slot are designed as a plane, sphere and cone shape respectively, then the influence of oil-air guidance slot structure on the performance of distributor is analyzed in the oil-air lubrication system in this paper. The results show that the spherical surface and conical surface of oil-air guidance slot can improve the uniformity and stability of the oil and air two-phase flow distribution, promote the flow pattern to form a continuous annular oil film. Among these three structures of oil-air guidance slot, we also find that the distribution performance of conical surface is the best.

• Periodical: Advanced Materials Research (Volumes 889-890)
• Pages: 352-357
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.889-890.352
• Online since: February 2014
• Authors: Qi Guo Sun, Zheng Hui Zhou*, Hong Bo Lv, Yue Fei Wang
• Keywords: Distribution Performance, Distributor, Oil-Air Guidance Slot, Oil-Air Lubrication

References

[1] Yang Zhonghe, Liu Houfei. Oil-air Lubrication Technology(1)[J]. Lubrication and Sealing, 2003, (1): 107~109.

[2] Wu Jianrong. Research of Oil-air Lubrication System and Application in the Hot Skin Pass Mill[D]. Shenyang: Northeastern Uninversity, 2006: 1-5.

[3] Wang Zhikun. Experimental Research on Oil-air Two Phase Lubrication of High Speed Bearing[D]. Nanjing: Southeast University, (2005).

[4] Cai Maolin. Oil-air Distributor. Taiwan China. CN2394086Y. 2000-06-24.

[5] Lican. Structure Design and Performance Simulation of the Oil-air Distributor[D]. Beijing: North China University of Technology, (2013).
