Fractal Analysis of Morphological Image of Organic Phthalocyanine Tetrasulfonic Acid Tetrasodium (TsNiPc) Film

Abstract:

Surface morphology of thin films can be efficiently characterized using power spectral density method. Spectral based parameters from surface models can then be linked to electrical conductivity of thin films used for fabricating organic photovoltaic devices. In this study, the surface morphologies of the organic thin films phthalocyanine tetrasulfonic acid tetrasodium (TsNiPc) are investigated using atomic force microscopy. The thin film samples are imaged at 40-minutes and 120-minutes after the solvent treatment. The spectral exponent β is determined from the slope of PSD log-log plot and the fractal dimension D of each film is calculated based on fractal relation β = 8 2D. The relationship between surface roughness and fractal dimension with respect to electrical properties of thin film is discussed.

• Periodical: Advanced Materials Research (Volume 895)
• Pages: 407-410
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.895.407
• Online since: February 2014
• Authors: Yeo Lee Kong*, S.V. Muniandy, M.S. Fakir, K. Sulaiman
• Keywords: Fractal Dimension, Locally Self-Similar Processes, Morpholoy, Power Spectral Density

References

[1] N. Betrouni, R. Lopes, Fractal and multifractal analysis: A review., Journal of Medical Image Analysis 13, 634–649, (2009).

DOI: 10.1016/j.media.2009.05.003

[2] S. Thakur, R.B. Tokas, N.K. Sahoo, Fractals and superstructures in gadolinia thin film morphology: Influence of process variables on their characteristic parameters, Thin Solid Films 503, 85 – 95, (2006).

DOI: 10.1016/j.tsf.2005.11.107

[3] I. Degasne, G. Huré, E. Legrand, M. Audran M.F. Baslé, D. Chappard, Image analysis measurements of roughness by texture and fractal analysis correlate with contact profilometry, Journal of Biomaterials 24, 1399–1407, (2003).

DOI: 10.1016/s0142-9612(02)00524-0

[4] B. B Mandelbrot, J W. Van Ness, Fractional Brownian motion, Fractional Noises and Applications. SIAM Review 10, 422 - 437, (1968).

DOI: 10.1137/1010093

[5] T. Gneiting, M. Schlather, Stochastic models that separate fractal dimension and Hurst effect, SIAM Review 46, 269–282, (2004).

DOI: 10.1137/s0036144501394387

[6] M. S. Fakir, Modification of Optical Band Gap and Surface Morphology of NiTsPc Thin Films, Chinese Physics Letter 29, 126802, (2012).

DOI: 10.1088/0256-307x/29/12/126802

[7] Z. Ahmad, S. M. Abdullah, K. Sulaiman, Temperature-sensitive chemical cell based on Nickel (II) phthalocyanine-tetrasulfonic acid tetrasodium salt, Sensors and Actuators A179, 146-150, (2012).

DOI: 10.1016/j.sna.2012.03.037

[8] N.K. Sahoo, S. Thakur, R.B. Tokas M. Senthilkumar, Characterization of microroughness parameters in gadolinium oxide thin films: A study based on extended power spectral density analyses., Applied Surface Science 252, 1608-1619, (2005).

DOI: 10.1016/j.apsusc.2005.02.122

[9] D. Raoufi, Fractal analyses of ITO thin films: A study based on power spectral density, Physica B 405, 451-455, (2010).

DOI: 10.1016/j.physb.2009.09.005
