Sol-Gel Derived ZnO Nanorod Templated TiO₂ Nanotube Synthesis for Natural Dye Sensitized Solar Cell

Abstract:

Natural dye sensitized solar cells (nDSSC) mostly suffer from low solar cell performance, that vertically aligned nanotube TiO₂ as the photoanode is expected to increase the performance by providing higher surface area and direct electron transport. Nanostructured TiO₂ films have been fabricated on glass substrates employing ZnO nanorod films as the template. First, vertically oriented ZnO nanorod on a glass substrate was prepared hydrothermally. Then, sol-gel dip-coating technique was used to deposit TiO₂. The template films were dip-coated into sols of titanium tetraisopropoxide-ethanol-diethanol ammine with withdrawing rate of 2 cm/min for three- (Ti3) and seven-times (Ti7). After drying at 100 °C for 10 min, the films were calcined at 550 °C for 1h and washed with HCl 3% (v/v). The films were characterized by X-ray diffraction (XRD), Scanning Electron Microscopy (SEM) and Transmission Electron Microscopy (TEM). It is observed that different coating cycles resulted in different film morphologies. Nanotube TiO₂ with diameter of ~50 nm was identified for Ti3, while Ti7 displayed sheet-like structure. The diffraction patterns confirmed the presence of only anatase crystalline phase with crystallite size of 10.3 nm (Ti3) and 21.7 nm (Ti7). The dye absorption was red-shifted indicating dye monomeric adsorption on TiO₂ via chelation. Enhanced absorption of anthocyanin dye extracted from pericarps of mangosteen (Garcinia mangostana l.) fruit on TiO₂ nanotube compared to TiO₂ nanoparticle (P25) was observed leading to improved photovoltaic performance of the constructed nDSSC.

• Periodical: Advanced Materials Research (Volume 896)
• Pages: 485-488
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.896.485
• Online since: February 2014
• Authors: Indriana Kartini*, Evana Evana, Sutarno Sutarno, Chotimah Chotimah
• Keywords: Mangosteen Dye, Solar Cell, Template Sol-Gel, TiO₂ Nanotube, ZnO Nanorod

References

[1] S. Hao, J. Wu, Y. Huang, J. Lin, Natural dyes as photosensitizers for dye-sensitized solar cell, Sol. Energy 80 (2) (2006) 209-214.

DOI: 10.1016/j.solener.2005.05.009

[2] S. Meng, J. Ren, E. Kaxiras, Natural dyes adsorbed on TiO2 nanowire for photovoltaic applications: Enhanced light absorption and ultrafast electron injection, Nano Lett. 8(10) (2008) 3266-3272.

DOI: 10.1021/nl801644d

[3] F. Shao, J. Sun, L. Gao, S. W. Yang, J. Q. Luo, Growth of various TiO2 nanostructures for dye-sensitized solar cells, J. Phys. Chem. C 115 (2011) 1819-1823.

DOI: 10.1021/jp110743m

[4] J. H. Park, T. W. Lee, M. G. Kang, Growth, detachment and transfer of highly-ordered TiO2 nanotube arrays: use in dye-sensitized solar cells, Chem. Commun. (2008) 2867-2869.

DOI: 10.1039/b800660a

[5] T. Kasuga, M. Hiramatsu, A. Hoson, T. Sekino, K. Niihara, Titania nanotubes prepared by chemical processing, Adv. Mater. 11 (1999) 1307-1311.

DOI: 10.1002/(sici)1521-4095(199910)11:15<1307::aid-adma1307>3.0.co;2-h

[6] D. Gong, C.A. Grimes, O.K. Varghese, Z. Chen, W. Hu, E.C. Dickey, Titanium oxide nanotube arrays prepared by anodic oxidation, J. Mater. Res. 16 (2001) 3331-3334.

DOI: 10.1557/jmr.2001.0457

[7] J.H. Lee, I.C. Leu, M.C. Hsu, Y.W. Chung, M.H. Hon, Fabrication of aligned TiO2 one-dimensional nanostructured arrays using a one-step templating solution approach, J. Phys. Chem. B 109 (2005) 13056-13059.

DOI: 10.1021/jp052203l

[8] S. Yoshikawa, T. Sagawa, T. Rattanavoravipa, Photovoltaic performance of hybrid solar cells with TiO2 nanotubes arrays fabricated through liquid deposition using ZnO template, Sol. Energy Mater. Sol. Cells., 92 (2008) 1445–1449.

DOI: 10.1016/j.solmat.2008.06.011

[9] J. Qiu, Z. Jin, Z. Liu, X. Liu, G. Liu, W. Wu, X. Zhang, X. Gao, Fabrication of TiO2 nanotube film by well-aligned ZnO nanorod array film and sol–gel process, Thin Solid Films 515 (2007) 2897–2902.

DOI: 10.1016/j.tsf.2006.08.023

[10] Q. Dai, J. Rabbani, Photosensitization of nanocrystalline TiO2 films by anthocyanin dyes, J. Photochem. Photobiol. A: Chem. 148 (2002) 17-24.

[11] I. Kartini, Evana, Chotimah, Glucose templated hydrothermal synthesis of porous nanocrystalline anatase TiO2, Asian J. Chem. 22(6) (2010) 4501-4510.
