High Performance Current-Voltage Characterization System for High Resistance Materials

Abstract:

The resistivity measurement finds many applications in semiconductors and insulating materials characterization. Conventional digital multimeter can provide resistance measurement up to about 10-200MΩ. However, in some cases, resistances in gigaohms (GΩs) and higher ranges need to be measured accurately. To measure the resistance of high resistivity materials, a programmable voltage source (-100V to +100V) combined with an electrometer system (100pA 10mA) have been built. The electrometer system and programmable voltage source have been calibrated with a calibrator (Fluke 5100B series) and digital multimeter (Fluke 8808A). Materials resistance up to 10 GΩ can be obtained by measuring the current-voltage (I-V) characteristics. It is found that the I-V curve of the 10 GΩ resistor fits very well the linear function with a high linear regression coefficient R² of 0.999.

You might also be interested in these eBooks

Advanced Materials Science and Technology

View Preview

Info:

Periodical:

Advanced Materials Research (Volume 896)

Pages:

710-713

DOI:

https://doi.org/10.4028/www.scientific.net/AMR.896.710

Citation:

Cite this paper

Online since:

February 2014

Authors:

Muhammad Miftahul Munir*, Yundi Supriadani, Maman Budiman, Khairurrijal Khairurrijal

Keywords:

Currentvoltage Characterization, Electrometer, High Resistance Materials, Programmable Voltage Source

Export:

RIS, BibTeX

Price:

Permissions CCC:

Request Permissions

Permissions PLS:

Request Permissions

Сopyright:

Citation:

* - Corresponding Author

References

[1] X. Huai, S. Zhao, and W. Li. Corrosion resistance of Al2O3 coating on a steel substrate., J. Ceram. Process. Res., 10. 5 (2009): 618-620.

Google Scholar

[2] Handbook, L. L. M. (2004). Precision DC Current. Voltage, and Resistance Measurements, 6th edition (Keithley Instruments, Cleveland, OH, 2004).

Google Scholar

[3] Khairurrijal, M. Abdullah, A. Suhendi, M.M. Munir, A. Surachman, A simple microcontroller-based current electrometer made from LOG112 and C8051F006 for measuring current in metal-oxide-semiconductor devices, Meas. Sci. Technol., 18 (2007).

DOI: 10.1088/0957-0233/18/9/037

Google Scholar

[4] Khairurrijal, M. Abdullah, M.M. Munir, A. Surachman, A. Suhendi, Low Cost and User-friendly Electronic Components Characterization System for Undergraduate Students, WSEAS Trans. Adv. Eng. Educ., 3 (2006). 971-976.

Google Scholar
