The Simulation of Rolling Process of Bar

Abstract:

The three-dimensional models of rolling are established with Pro/E. Based on the finite element analysis software ANSYS/LS-DYNA, the procedure of bar tandem rolling is simulated. The nephograms of stress and strain of bar deformed area and the curve of roll force during rolling are obtained. Compared the result with the other result which comes from optimization, the precision of calculation will be verified.
