A Scheduler Design for Coordinating Network Control System Load with Redundancy

Abstract:

For a network control system (NCS) with redundancy structure, this paper designs a network scheduler, which can coordinate network load and support redundancy to enhance system availability, safety and reliability. Considering the Quality of Service (QoS) and the Quality of Control (QoC) to constitute the objective function of network resources scheduling, the scheduler uses fuzzy system to establish the network resource scheduling strategy, which dynamically decides communication channels of network control loops by calculating online and real-time scheduling. The scheduler can improve real-time performance and availability of the NCS, and quickly switch redundancy network under fault conditions to ensure reliability of the NCS. At last, the experiment results demonstrate that the proposed scheduler meets the requirements of the resource scheduling and redundancy network, and can effectively improve the performance of the NCS when network load increases.

• Periodical: Advanced Materials Research (Volume 898)
• Pages: 624-628
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.898.624
• Online since: February 2014
• Authors: Zheng Fu Peng, Wei Huang*, Juan Liu, Yue Yue Lv
• Keywords: Fuzzy Scheduler, Network Control System (NCS), Quality of Control (QoC), Quality of Service (QoS), Redundancy Network

References

[1] HESPANHA J P, NAGHSHTABRIZI P, XU Y. Proc. IEEE, 2007, 95(1): 138-162.

[2] WANG Y Q, YE H, DING S, et al. Automatica, 2009, 45(10): 2427-2434.

[3] Dajun Du, Minrui Fei. Chinese Journal of Scientific Instrument, 2011, 32(3): 713-720.

[4] Nian Liu, Xulun Zhou, Yande Shen. Control Engineering of China, 2011, 18(3): 429-433.

[5] Zhongda Tian, Xianwen Gao. Electric Machines and Control, 2013, 17(1): 94-101.

[6] Xiao Wu, Jian Wu. Measurement and Control Technology, 2010, 29(2): 78-84.

[7] Xuan Hung Nguyen, Guy Juanole, Gerard Mouney. 2010 8th IEEE International Workshop on Digital Object Identifier.

[8] Michael S. Branicky, Stephen M. Phillips, Wei Zhang. Scheduling and Feedback Co-Design for Networked Control Systems [C] /Proceeding of the 41st IEEE Conference on Decision and Control, December, 2002, Las Vegas, Nevada USA.

DOI: 10.1109/cdc.2002.1184679

[9] Dandan Chen, Li Xia, Haifeng Wang. Scheduling Algorithm in Networked Control Systems based on Importance [C] /2008 ISECS International Colloquium on Computing, Communication, Control, and Management.

DOI: 10.1109/cccm.2008.204

[10] Feng Xia, Xiaohua Dai, Zhi Wang, et al. Feedback Based Network Scheduling of Networked Control Systems [C]. /2005 International Conference on Control and Automation (ICCA2005), June 27-29, 2005, Budapest, Hungary.

DOI: 10.1109/icca.2005.1528309

[11] Hongwei Zhang, Wenjuan Zhang. Journal of Northeast Normal University, 45(1): 65-70.

[12] Junbo Wang, Bugong Xu. Control and Decision, 2008, 23(5): 551-554.
