Research of Fluxless Soldering of High-Purity Aluminium with Solders Type Zn-Al

Abstract:

The aim of work consists in the study of interactions on solder/substrate boundary in fluxless soldering of Al with 4N purity by ultrasound activation. The ZnAg6Al6 and ZnAl4 solders were used in experiments. The soldering parameters were as follows: soldering temperature from 400 oC to 420 oC, acting time of ultrasonic vibrations 5 to 20 s, ultrasound frequency 40 kHz. Soldered joints were assessed by optical light microscopy, EDXmicroanalysis and XRD analysis. It was found out that the ZnAg6Al6 solder is composed of αAl, βZn solid solutions and AgZn₃phase. The ZnAl4solder consists of βZn primary solid solution and a lamellar eutectic Zn-Al structure. The main mechanism of joint formation between the solders type Zn-Al and Al substrate during soldering consists in eutectic reaction between the liquid Zn and solid Al. An eutectic βZn-αAl mixture was observed on the joint boundary in case of both solders. In case of Al/ZnAg6Al6 joint also AgZn₃intermetallic compound was observed in the transition zone.

You might also be interested in these eBooks

Advances in Applied Materials and Electronics Engineering III

View Preview

Info:

Periodical:

Advanced Materials Research (Volume 905)

Pages:

132-136

DOI:

https://doi.org/10.4028/www.scientific.net/AMR.905.132

Citation:

Cite this paper

Online since:

April 2014

Authors:

Roman Koleňák*, Igor Kostolný, Roman Čička

Keywords:

Fluxless Soldering, High-Purityaluminium, Ultrasonicactivation, Zn-Al Solder

Export:

RIS, BibTeX

Price:

Permissions CCC:

Request Permissions

Permissions PLS:

Request Permissions

Сopyright:

Citation:

* - Corresponding Author

References

[1] Ch. C. Lee and J. Kim: AdvancedPackagingMaterials: Processes, Properties and Interfaces, 2005, pp.33-38.

Google Scholar

[2] A. E. Gickler, F. H. LePrevost Jr., T. Pan, A. M. Jaoquin, C. A. Blue and M. L. Santella: AluminiumSoldering - A New Look, (2003).

Google Scholar

[3] Y. Li, W. Zhao, X. Leng, Q. Fu, L. Wang and J. Yan: Trans. Nonferrous Met. Soc. China21, 2011, p.1937-(1943).

Google Scholar

[4] Y. Xiao, H. Ji, M. Li and J. Kim: Materials and Design 52, 2013, p.740–747.

Google Scholar

[5] N. Kang, H. S. Na, S. J. Kim and Ch. Y. Kang: JournalofAlloys and Compounds 467, 2009, p.246–250.

Google Scholar

[6] A. Haque, Y. S. Won, A. S. M. A. Haseeb, H. H. Masjuki: Investigations on Zn-Al-GeAlloysasHighTemperatureDieAttachMaterial, UniversityofMalaysia, Kuala Lumpur, Malaysia.

Google Scholar

[7] T. Shimizu, H. Ishakawa, I. Ohnuma and K. Ishida: JournalofElectronicMaterials, Volume 28, Issue 11, 1999, pp.1172-1175.

Google Scholar

[8] Y. Takaku, L. Felicia, I. Ohnuma, R. Kainuma and K. Ishida: JournalofElectronicMaterials, Volume 37, Issue 3, 2008, pp.314-323.

Google Scholar

[9] L. Cintavý, 2012: Beztavivovýspôsobspájkovaniahliníka a jehozliatin /Fluxless method of soldering aluminium and its alloys, Thesis, MTF STU Trnava, 74 p.

Google Scholar
