Failure Prediction of Normally Consolidated Clays Using Stress Paths of Consolidated Undrained Tests

Abstract:

A new method of stability evaluation of the stage-constructed embankment on soft ground using stress path is developed and presented in this paper. A series of CU tests was carried out to develop the new method to evaluate the stability of soft ground. A new concept of stability index (SI) is defined with stress path. The effective stress path (ESP) line approaches to the K_f line gradually along the same direction to a certain point, then the direction changes and approaches to the K_f line rapidly. The potential of failure increases swiftly when SI is less than 0.4, and the value of SI=0.4 could be assumed as a representative value to evaluate the potential of failure for the tested material.

You might also be interested in these eBooks

Key Engineering Materials - Development and Application

View Preview

Info:

Periodical:

Advanced Materials Research (Volume 911)

Pages:

499-503

DOI:

https://doi.org/10.4028/www.scientific.net/AMR.911.499

Citation:

Cite this paper

Online since:

March 2014

Authors:

Jong Ryeol Kim*, Galym Zhumabekov, Dias Bakhtiyarov, Dilmurat Saliyev

Keywords:

Cu Test, Embankment on Soft Ground, Potential of Failure, Stability Evaluation, Stability Index (SI), Stress Path

Export:

RIS, BibTeX

Price:

Permissions CCC:

Request Permissions

Permissions PLS:

Request Permissions

Сopyright:

Citation:

* - Corresponding Author

References

[1] ASTM D4767-11 (2011). Standard Test Method for Consolidated Undrained Triaxial Compression Test for Cohesive Soils. ASTM International, West Conshohocken, PA.

DOI: 10.1520/d4767-11r20

Google Scholar

[2] Balasbramanium, A. S. and Brenner, E. W. (1981), Consolidation and settlement of soft clay, Soft Clay Engineering, Elsevier, p.479~566.

DOI: 10.1016/b978-0-444-41784-8.50010-1

Google Scholar

[3] Duncan, J. M. and Chang, C. Y. (1970), Nonlinear analysis of stress and strain in soil, J. Geotech. Engineering, ASCE, Vol. 96, No. SM5, p.1629~1653.

Google Scholar

[4] Lambe, T. W. (1964), Methods of estimating settlement, J. of Soil Mech. and Foundation Division, ASCE Vol. 90, No. SM5, pp.47-74.

Google Scholar

[5] Leroueil, S., Magna, J. and Tavenas, F. (1990), Embankment on Soft Clays, Ellis Horwood.

Google Scholar

[6] Schmertmann J. M. (1955), The undisturbed consolidation behavior of clay, Transaction of ASCE, Vol. 120, p.1201~1211.

Google Scholar

[7] Spence, R. A., and Glynn, T. E. (1962), Shear characteristics of a marine clay, J. Soil Mech. Found. Div., ASCE, SM4, August, p.85~107.

DOI: 10.1061/jsfeaq.0000449

Google Scholar
