The Creation of the Mathematical Model of Involute Gear Modeling

Abstract:

The paper puts forward a way to establish the mathematical model of involute gear according to the basic knowledge of mechanical design and method of mathematical analysis. A data file of coordinates of a series of points is generated by the use of powerful data analysis and mathematical calculation function of Excel. Based on this, involute and helix of high precision are designed through the seamless joint of Solid Edge and Excel. Then accurately modeling of involute gear can be realized. After modeling, high-precision gear can be manufactured through CNC machining to meet the equipment requirements for gear accuracy.
