Design of Retaining and Protecting for a Deep Foundation Excavation

Abstract:

Urban development often requires the construction of deep excavations. There are some difficulties during design and construction of foundation excavation, such as large engineering quantity, poor geological conditions, as well as challenges to design and construction of retaining and protecting structure. To solve these difficulties, supporting system of steel circle beam, steel pipe support and stiffened support compounding with steel pipe pile cofferdam is designed. Soil resistance calculating method is used for support structure design in all possible conditions and the result is compared with that using the classical method. With reasonable supporting process and construction measures, monitoring results including displacement of steel pipe piles and greatest axial force can meet the norm requirements. It is proved that the retaining and protecting system designed is safe and reliable. With the benefit of small deformation and high integrity, locking steel pipe piles gave full play to its locking function of water. The design method in the paper is feasible and may offer some references for similar deep foundation excavation.

• Periodical: Advanced Materials Research (Volumes 919-921)
• Pages: 1416-1420
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.919-921.1416
• Online since: April 2014
• Authors: Hui Wu Jin*
• Keywords: Circle Beam, Foundation Excavation, Retaining and Protecting, Steel Pipe Pile Cofferdam

References

[1] Lefas, I.D. and V.N. Georgiannou, Analysis of a cofferdam support and design implications. Computers and Structures, 2001. 79(26).

DOI: 10.1016/s0045-7949(01)00082-7

[2] Benmebarek, N., S. Benmebarek, and R. Kastner, Numerical studies of seepage failure of sand within a cofferdam. Computers and Geotechnics, 2005. 32(4).

DOI: 10.1016/j.compgeo.2005.03.001

[3] Noh, J., et al., Numerical modeling of flow and scouring around a cofferdam. Journal of Hydro-environment Research, 2012. 6(4).

DOI: 10.1016/j.jher.2011.08.005

[4] Wang, C. and Y. Zhou, Application of Bayesian Approach in Back Analysis of the Break Rate of Overtopped Earth-rock Cofferdam. Procedia Engineering, 2012. 28.

DOI: 10.1016/j.proeng.2012.01.771

[5] Gui, M. -W. and K. -K. Han, An investigation on a failed double-wall cofferdam during construction. Engineering Failure Analysis, 2008. 16(1).

DOI: 10.1016/j.engfailanal.2008.06.004

[6] Jian-hang Liu, Xue-yuan Hou. (2005). The manual of foundation pit cutting. Beijing: China's construction industry press.

[7] Technical Specification for Retaining and Protecting for Building Foundation Excavations. JGJ120-99. (1999). Beijing: China's construction industry press.

[8] Jin-huo Zheng. SMW application in the soft deep foundation pit cutting in Fuzhou city. Fujian Construction Science & Technology, 2009(1).
