Application of the Failure Assessment Method for Cracked Pipeline

Abstract:

A new failure assessment curve of pipeline containing crack is provided in this paper. The new failure assessment curve is based on the J integral calculation method of the effective remote stress, and it is as simple as the R6 option 2. The result of the new failure assessment curve is as accurate as the result of the curve based on strict J integral. Moreover, the new failure assessment curve could be used for any stress-strain relationship material, including Ramborg-Osgood (R-O) material and non-R-O materials under monotonic increasing loading, such as long plastic yield plateau steel. The new failure assessment curve is applied to a case that came from the three pipes burst in a proof test of an oil pipeline. Comparison with the result in the proof test shows the result of the new failure curve presented in this paper is accurate.

• Periodical: Advanced Materials Research (Volumes 919-921)
• Pages: 455-459
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.919-921.455
• Online since: April 2014
• Authors: Yong Qiang Bai*, Liang Hai Lv, Tong Wang, Xiao Feng Zhang
• Keywords: Crack, Effective Remote Stress, Failure Assessment Curve, Failure Assessment Diagram, Pipeline

References

[1] Central Electricity Generating Board. Assessment of the integrity of structures containing defects[R]. CEGB Report R/H/R6, 1976; Revision 1, 1977; Revision 2, 1988; Revision 3.

[2] Kumar V, German M D, Shih C F. Translated by ZHOU Hongfan. An engineering approach for elastic-plastic fracture analysis[M]. Beijing National Defense Publishing House, 1985(in Chinese).

[3] BAI Yongqiang, WANG Tong, SUN Liang, CHEN Gang, SHUAI Jian. Failure Assessment Curves Based on the Effective Remote Stress[J]. Journal of Mechanical Strength, 2008, 30(4): 638-641(In Chinese).

[4] SUN Liang, LI Peining, LIU ChangJun. Equivalent remote stress method of J integral evaluation for any stress-strain relationship materials[J]. Journal of Mechanical Strength, 2003, 25(4): 450-455(In Chinese).

[5] SUN Liang. A J-integral estimation approach in terms of effective remote stress and the database of J-integral solutions for three-dimension cracked structure [D]. Shanghai: East China University of Science & Technology, 2000(In Chinese).

[6] Ainsworth R A. The assessment of defects in structures of strain hardening material[J]. Engineering Fracture Mechanics, 1984, 19(4): 633-644.

DOI: 10.1016/0013-7944(84)90096-1

[7] Wark W R, Chen Min, Wilks G W. Translated by WANG Xinhu. Final report for Fitness-for-service assessment of pipes of Kulun oil depot[R]. Xi An: Tubular Goods Research Center of CNPC, 1995. 6 (In Chinese).
