Effect Analysis on Tunnel Serviceability State by the above Expressway Extension in Loess Area

Abstract:

Based on the typical adjacent project of extension of LianHuo expressway which is constructed on WenXiang tunnel, the finite difference software, Flac3D, is adopted to stimulate the process of the construction. In this paper, from two aspects, the deformation of profile and cross-section, serviceability state is analyzed in detail. In the profile plot, usually displacement of the invert arch is less than that of the vault, and affected by the mutual position of topography and excavation, the maximum displacement, 6.3mm, merges at 50m of the vault in the profile plot; in the cross-section plot, due to occurrence of unloading effect brought by overlying excavation, tunnel structure has the tendency of rising toward the excavation. The calculated result shows that the displacement of WenXiang tunnel locating on the line of ZhengZhou-Xi’an Railway High-speed can be well controlled by adopting the excavation method of layering excavation at vertical direction and section excavation at longitudinal direction, which makes the safety of serviceability state of extension of expressway and the operation of Railway High-speed.

• Periodical: Advanced Materials Research (Volumes 919-921)
• Pages: 846-852
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.919-921.846
• Online since: April 2014
• Authors: Ke Guo Sun*, Chao Kong, Wen Ge Qiu, Kai Liu, Wei Ping Xu, Lun Gong
• Keywords: FLAC3D, Loess Area, Serviceability State, Structure Uplift, Underlying Tunnel

References

[1] Qiu Wenge. Research on mechanical principle of adjacent construction and the countermeasures [D]. Ph. D thesis in Southwest Jiaotong University, (2003).

[2] Zheng Yuchao. Research on the impact of the three holes parallel adjacent construction of shield tunnel [D]. Ph. D thesis in Southwest Jiaotong University, (2006).

[3] Gong Lun. Proximity Principle and Countermeasure of construction mechanics down cross tunnel [D]. Ph. D thesis in Southwest Jiaotong University, (2007).

[4] Liu Zhaowei, Yang Shiwu. A municipal tunnel beneath existing railway Excavation Technology [J]. Journal of Geotechnical Engineering, 2006, 28(3): 353- 357.

[5] Li Wei, He Chuan. Shield tunnels traversing study the impact of large underground structure construction [J]. Journal of Geotechnical Engineering, 2006, 28(10): 1277- 1282.

[6] Zhang Chengping, Yang Dingli, Wang Mengshu. Deformation of overlying subway tunnel structure induced by tunneling [J]. Journal of Geotechnical Engineering, 2009, 31(5): 805- 810.

[7] New construction loads ground impact analysis study of the longitudinal deformation of adjacent metro tunnels [J]. Journal of Geotechnical Engineering, 2006, 28(3): 312- 316.
