Finite Element Analysis Based on ANSYS of Bolt of Roof Bolter

Abstract:

The three-dimensional solid models of five different length and shaft diameter anchor of bolt were constructed based on ANSYS software, and making static analysis and modal analysis on it to obtain the stress nephogram and natural frequency of bolt. Research on the stress condition of bolt in static analysis. In modal analysis, researching on the effect regular of the change of length and shaft diameter size on the bolt transverse vibration, the longitudinal and torsional vibration of three natural modes of different frequency, providing a reference for the structure design and reasonable choice of bolt type for corresponding condition.
